LG918 2904000761 Torque converter system

1 29040006521 接头体 Nipple Y 2

2 4030000211 O形圈GB3452.1-30.0*2.65G O-ring Y 2

3 29040007621 变速泵至滤清器胶管 Hose assembly Y 1

4 4011000481 螺栓GB16674-M8*30EpZn-8.8 Bolt Y 2

5 29040006541 滤清器至变矩器胶管 Hose assembly Y 1

6 4030000267 胶管JB8406-B19*450 Hose Y 1

7 4017000011 喉箍JB8870-d32 Clamp Y 6

8 4030000207 胶管JB8406-B19*1100 Hose Y 1

9 29040006551 接头体 Nipple Y 1

10 4030000059 垫圈JB1002-20-T2 Washer Y 1

11 4011000085 螺栓GB5783-M10*35EpZn-8.8 Bolt Y 12

12 4015000025 垫圈GB93-10-65Mn Spring washer Y 12

13 4110000507 滤清器QF60M33G-1 Oil filter Y 1

14 4011000147 螺栓JB999-M27*2*55EpZn-35 Bolt Y 1

15 4030000062 垫圈JB1002-27-T2 Washer Y 2

16 4110000217 变矩器YJ280-4DL Torque converter Y 1

17 29350000021 管夹 Hose clamp Y 1

18 4011000461 螺栓GB16674-M8*16EpZn-8.8 Bolt Y 1

19 29040006581 变矩器至变速阀胶管 Hose assembly Y 1

20 4030000179 O形圈GB3452.1-8.50*1.80G O-ring Y 2

21 4120000174 胶管JB8406-B19*900 Hose assembly Y 1
