LG918 4110000217 变矩器(370804) Torque converter

1 4110000960006 螺栓 M12X25 01010-81225 Screw Y 15

2 4110000160054 垫圈01602-21236 Gasket Y 16

3 4110000011116 圆垫板YB315Z5-04 Shim Y 1

4 4110000217071 弹性板YJ265-00002 Plate Y 1

5 4110000217072 弹性板总成YJ265-10000 Plate Y 1

6 4013000162 螺母GB6170-M8-8 Nut Y 24

7 4011000061 螺栓GB5782-M12*35EpZn-8.8 Bolt Y 1

8 4110000084130 垫圈8 01602-20825 Washer Y 40

9 7200000857 垫片YJ280-1C-00004 Shim N 1

10 4110000194006 螺母M12-01580-11210 Nut Y 9

11 4110000217039 罩轮YJ280-1C-00005 Cover Y 1

12 4110000217073 挡圈04064-05020 50 Washer Y 3

13 4021000011 滚动轴承GB276-6010 Ball bearing Y 5

14 7200000804 垫板YJ280-4A-10002 Plate N 1

15 4110000004015 涡轮YJ280-4A-10003 Turbine N 1

16 4110000084103 挡圈04064-03818 Retaining ring Y 2

17 7200000807 涡轮毂YJ280-4A-10001 Turbo housing kit N 1

18 4110000217036 O形圈YJ315D-00022B O-ring Y 1

19 7200000809 铆钉8*2004400-00820 Rivet N 10

20 4110000217064 挡圈04064-05520 55 Washer Y 1

21 4110000217041 导轮YJ280-4A-00005 Stator N 1

22 4030000616 O形圈GB3452.1-300*3.55G O-ring Y 1

23 4110000004007 泵轮YJ280-4A-00006 Impeller Y 1

24 4015000381 垫圈GB7244-10-65Mn Washer N 41

25 4110002525001 螺栓01010-80835 M8*35 Screw Y 24

26 4110000004016 O 型圈 130×3.1 07000-E2130 O-ring Y 1

27 4015000241 挡圈GB893.1-110-65Mn Retaining ring Y 1

28 4021000113 滚动轴承GB276-6212 Ball bearing Y 1

29 4110000217022 泵轮座YJ2804A00015 Seat Y 1

30 4110000217048 垫片1YJ315D-00021B Rubber washer Y 1

31 4110000084064 定位销ZL30D-11-22 Pin Y 4

32 4110000004019 螺栓 M8×22 01010-80822 Screw Y 8

33 4110000217054 盖板YJ280-4A-00007 Cover plate Y 2

34 4110002525003 螺栓01010-80816 M8*16 Screw Y 8

35 4110000217047 输出法兰YJ315D-00020B Flange Y 1

36 4110000217040 中节YJ280-4A-00001 Flange Y 1

37 4110000217084 密封垫YJ280-4A-00016 Gasket Y 1

38 4110000217052 骨架油封ZL30D-11-54 100*120*13 Sealing ring Y 1

39 4110000217057 螺栓01010-81095 M10*95 Screw Y 4

40 4110000960010 螺栓Bolt M10X30 01010-81030 Screw Y 21

41 4110000004020 螺栓 M10×40 01010-81040 Screw Y 12

42 4110002580011 骨架油封07012-70055 Sealing ring Y 1

43 4110000217095 挡圈20 04064-02010 Washer N 1

44 4110000004014 油泵轴YJ280-4A-00017 Pump shaft Y 1

45 4110000217065 挡圈04064-08025 80 Washer Y 1

46 4110000217028 油封座YJ2801C00003 Seat Y 1

47 4110000004013 轴套YJ280-4A-00009 Bushing Y 2

48 4110000217046 齿轮YJ280-4DL-00002 Gear Y 2

49 4110000217099 回油阀YJ265-40000 Oil valve Y 1

50 4110000217049 呼吸器YJ320-20000 Breather cap Y 1

51 4110000217067 吊环螺钉04530-11222 M12×22 Screw Y 1

52 4110000217019 齿轮箱YJ2801C00001 Housing Y 1

53 7200000836 挡圈3004065-03012 Retaining ring Y 1

54 4110000217043 油泵轴YJ280-4A-00010X Shaft N 1

55 4110000217045 齿轮YJ280-4DL-00001 Gear Y 1

56 4110000217061 挡圈04064-01030 100 Washer Y 1

57 4110000217051 密封环ZL30D-11-19 Spacer ring Y 2

58 4110000217037 纸垫YJ265-00012 Gasket Y 1

59 4110000217097 O型圈 07000-02125 O-ring Y 1

60 4110000217066 挡圈04065-09030 90 Washer Y 1

61 4110000217020 导轮座YJ2804A00014 Seat Y 1
62 7200000842 分油套YJ280-4A-00011 Sleeve Y 1
63 4110000217033 螺塞07043-00312 Plug Y 1
64 4110000218006 O 形圈07002-02434 O-ring Y 1
65 4110000218083 螺塞07044-12412 Plug Y 1
66 4110000217098 标牌YJ280-4DL-BP Name plate N 1
67 7200000846 铆钉3*6 04418-03060 Rivet Y 4
68 4110000217069 密封环YJ265-00014 Sealing ring Y 1
69 4110000217018 接头YJ2804C00007 Nipple Y 1
70 4110000217006 涡轮轴YJ2801C00002 Turbine shaft Y 1
71 4110000217001 减压阀YJ320-10000 Pressure reducing valve Y 1
72 4021000021 滚动轴承GB276-6308 Ball bearing Y 1
73 4110000960005 螺栓01010-81025 Screw Y 4
74 4110000217087 变速泵CB-FA25-FL-X Gear pump Y 1
