LG918 4110002407 水油散热器总成(370725) Radiator assembly
LG918 4110002407 水油散热器总成(370725) Radiator assembly
1 4110002407001 水散热器总成 LG920-5-1301100 Radiator Y 1
2 4110002407002 传动油散总成 LG920-5-1301300 Oil cooler Y 1
3 4110002407003 导风罩 LG920-5-1301600 Fan shroud Y 1
4 4110002407004 护网 LG920-5-1301610 Fan guard Y 1
5 4110002407005 左支架 LG920-5-1301630 Radiator bracket N 1
6 4110002407006 右支架总成 LG920-5-1301640 Radiator bracket N 1
7 6392200030 螺栓GB5781-M10*25EPZN-8.8 Screw N 18
8 4013000351 螺母GB41-M10-5 Nut Y 18
9 4110001929 Ⅱ型90Kpa复式加水口盖FG2 Cap Y 1
10 4110002407007 减震垫 LG920-5-1301650 Rubber mat N 2
11 4110002407008 挡风板 LG920-5-1301651 Wind deflector N 1
12 4110002407009 密封胶条 LG920-5-1301652 Sealing strip N 1
13 4110002407010 下挡板支撑板 LG920-5-1301653 Support plate N 1
14 4110002407011 上挡板支撑板 LG920-5-1301656 Support plate N 1
15 4011000962 螺栓GB/T5781-M8×20EpZn-8.8 Screw Y 30
16 4013000354 螺母GB41-M8 Nut Y 30
