L948F 燃油供给系统 Assembly compound A0130-2901005272

1 29010053871 燃油管 Fuel hose Y 1

2 4017000010 喉箍JB8870-d20 Clamp Y 5

3 29010031431 过渡接头 Nipple Y 1

4 4110002144 油水分离器11110709 Water separator Y 1

5 4011001381 螺栓GB16674.1-M10*35flZnyc-8.8-480 Screw Y 2

6 29010053881 燃油管 Fuel hose Y 1

7 4011001423 螺栓GB16674.1-M6*10flZnyc-8.8-480 Bolt Y 2

8 4011001297 螺栓GB16674.1-M8*16flZnyc-8.8-480 Screw Y 4

9 29010039981 安装板 Bracket Y 1

10 26370001941 管夹 Clamp N 2

11 29010047921 燃油管 Fuel hose Y 1

12 29010031371 接头 Nipple Y 3

13 4015000141 垫圈JB982-16 Washer Y 5

14 4011000641 螺栓JB6013-M14*1.5EpZn-45 Bolt Y 1

15 4015000121 垫圈JB982-14 Washer Y 2

16 26370003321 管夹30×45 Clamp Y 2

17 29010044741 透明胶管-500 Hose Y 1

18 4017000040 喉箍JB8870-d12 Clamp Y 1

19 4011000500 螺栓JB6013-M16*1.5-45 Bolt Y 1
