L948F 发动机安装系统 Engine mounting system A0140-2901005273

1 4011001310 螺栓GB5785-M20*1.5*130flZnyc-8.8-480 Screw Y 2

2 4013000379 螺母GB889.2-M20*1.5flZnyc-8-480 Nut Y 2

3 4015000434 垫圈GB97.1-20flZnyc-300HV-480 Washer Y 2

4 29050000101 减震块 Block Y 4

5 29050000121 垫圈 Washer Y 2

6 29010053891 左支架 Engine mounting Y 1

7 4011001387 螺栓GB5783-M16*45flZnyc-10.9-480 Bolt Y 4

8 4015000436 垫圈GB97.1-16flZnyc-300HV-480 Washer Y 4

9 4011001205 螺栓GB5783-M12*35flZnyc-10.9-480 Screw Y 2

10 4015000428 垫圈GB97.1-12flZnyc-300HV-480 Washer Y 2

11 29010053901 右支架 Engine mounting Y 1
