L953F 转向泵总成 Steering pump assembly I1900-2919001511

1 4041000730 软管LGB128-004070 Hose assembly Y 1

2 4011001300 螺栓GB16674.1-M10*30flZnyc-8.8-480 Screw Y 8

3 4041000043 分体法兰LGB117-310490 Flange half Y 1

4 4030000026 O形圈GB3452.1-32.5*3.55G O-ring Y 1

5 29190015131 转向泵出油胶管 Hose assembly Y 1

6 4030000029 O形圈GB3452.1-37.5*3.55G O-ring Y 2

7 29190016671 泵出油法兰 Flange Y 1

8 4011001298 螺栓GB16674.1-M10*55flZnyc-8.8-480 Screw Y 4

9 4120002266 双联泵JHP2100/Gj0010A-XF Gear pump Y 1

10 29110000043 泵用密封垫 Gasket Y 1

11 4012000100 螺柱GB898-M12*35flZnyc-10.9-480 Stud Y 4

12 4013000397 螺母GB6170-M12flZnyc-10-480 Nut Y 4

13 4015000428 垫圈GB97.1-12flZnyc-300HV-480 Washer Y 4

14 29190014751 转向泵吸油胶管 Hose Y 1

15 4017000013 喉箍JB8870-d90 Clamp Y 4

16 29190014742 转向泵吸油钢管 Pipe Y 1

17 4030000482 O形圈GB3452.1-50.0*3.55G O-ring Y 1

18 4011001530 螺栓GB16674.1-M12*60flZnyc-8.8-480 Screw Y 4

19 4041000865 软管LGB165-005050 Hose assembly Y 1

20 29190007921 直通接头体 Nipple Y 1

21 29120014931 垫圈 Washer Y 2

22 29120007651 接头 Nipple Y 1

23 4041001023 组合接头LGB143-01608 Nipple Y 1

24 4030000240 O形圈GB3452.1-8.00*1.80G O-ring Y 1

25 4041000027 分体法兰LGB117-312551 Flange half Y 1
