L953F 双联泵(370142) Gear pump I1901-4120002266

1 4120002266001 螺钉M16x179 01017-11679 Screw Y 4

2 4120000171042 平垫圈21061900110 Washer Y 2

3 4120000171043 弹簧垫圈41050200600 Spring washer Y 2

4 4120000171044 挡圈41060100200 Retaining ring Y 1

5 4120000171045 旋转轴唇形密封圈43020200100 Sealing ring Y 2

6 4120001084002 前盖21060200110 Cover Y 1

7 4120000171046 挡圈41060100100 Retaining ring Y 1

8 4120000171048 环形密封圈 44020100300 Sealing ring Y 1

9 4120000171049 滚针轴承42010100100 Needle bearing Y 4

10 4120000171050 定位套21020900110 Spacer sleeve Y 4

11 4120000171051 耳形挡片21020800110 Retaining ring Y 2

12 4120000171052 耳形密封垫21020700110 Sealing washer Y 2

13 4120000171053 侧板21020600110 Side board Y 2

14 4120002266002 主动齿轮轴 I HGP2100矩 21061012010 Drive shaft N 1

15 4120002266003 从动齿轮轴HGP2100 21020412010 Shaft N 1

16 4120002266004 泵体 I HGP2100 21061712010 Pump body N 1

17 4120000171057 环形密封圈 44020100600 Sealing ring Y 1

18 4120001084006 中间体21061200210 Centering block Y 1

19 4120000171059 挡圈41060100600 Retaining ring Y 1

20 4120000171060 环形密封圈 44020100200 Sealing ring Y 1

21 4120000171061 滚针轴承42010100300 Needle bearing Y 4

22 4120000171062 定位套21010900110 Spacer sleeve Y 4

23 4120000171063 耳形挡片21010800110 Retaining ring Y 2

24 4120000171064 耳形密封垫21010700110 Sealing washer Y 2

25 4120000171065 侧板21010600110 Side board Y 2

26 4120000171066 主动齿轮轴21061101010 Drive shaft Y 1

27 4120000171067 从动齿轮轴21010401010 Shaft Y 1

28 4120000171068 泵体21071801010 Pump body Y 1

29 4120000171069 O形圈43010102400 O-ring Y 1

30 4120005081016 环形密封圈 44020100100 Sealing ring Y 1

31 4120002266005 后盖HGP2/1-XF(B) 21070500310 Cover N 1

32 4120000171071 直动式溢流阀46000000100 Valve Y 1

33 4120000171072 螺钉44010100180 Screw Y 4

34 4120000171073 弹簧垫圈41050200800 Spring washer Y 4

35 4120002266006 密封件包 Sealing kit Y 1
