G9165 4110002575 变矩器部件YD13-030 The converter components

1 4110000076355 罩壳4166 330 931 Housing Y 1

2 4011000762 螺栓GB5783-M8*30EpZn-10.9 Bolt Y 30

3 4110000076002 纸垫 4166 330 227 Gasket Y 1

4 4021000018 滚动轴承GB276-6210 Ball bearing Y 1

5 4110000076397 调整垫片 4607 302 010 Shim Y 1

6 4110000076364 轴向垫圈 0635 290 050 AS6590 65*90*1 Gasket Y 1

7 4110000076363 轴向垫圈 0635 290 041 AS6585 60*85*1 Gasket N 1

8 4110000076005 轴向垫圈 0635 290 054 WS81113 Washer Y 1

9 4110000076006 箱体垫圈 0635 290 058 GS81112 Washer Y 1

10 4110000076007 滚柱推力轴承 0635 302 018 AX K6085 Bearing Y 1

11 4110000076008 滚柱推力轴承 0735 320 805 K81113L Bearing Y 1

12 4110000076316 法兰(泵轮) 4166 330 127 Flange Y 1

13 4110000076009 纸垫 4166 330 229 Gasket Y 1

14 4110002575001 螺栓 Bolt M8×20 DIN6912 8.8 Screw N 12

15 4015000251 P垫圈GB848-8EpZn-300HV Washer Y 12

16 4110000076010 泵轮4166332251 Impeller Y 1

17 4110000076011 涡轮4166332242 Turbine Y 1

18 4110000076301 导轮 4166 332 810 Stator Y 1

19 4110001905063 变矩器总成4166 032 009 Torque converter Y 1
