LG944MSK 4110000746 变速操纵机构LG936L Shift mechanism

1 4110000172006 手球LGH9530001 Handle ball Y 1
2 4110000172007 手柄组件LGH9530002 Bracket Y 1
3 4110000172008 盒罩LGH9530003 Cover Y 1
4 4110000172025 轴组件LGHD9530004 Bushing Y 1
5 4110000172010 螺母LGHD9530005 M10 Nut Y 1
6 4110000746003 M16尼龙帽LGH9530016 M16 nyong bonnet N 1
7 4110000172011 螺母LGHD9530006 M36 Nut Y 7
8 4110000746004 M5螺栓LGH9530006 Bolt Y 1
9 4110000172013 换挡盒LGHD9530008 Housing Y 1
10 4110000172009 固定板LG953HD0009 Bracket Y 1
11 4110000172015 螺栓LGHD9530010 M8 Screw Y 2
12 4110000172017 弹垫LGHD9530012 Spring washer Y 2
13 4110002042019 平垫Φ8 PD-002 Washer Y 2
14 4110000172018 销轴LGHD9530013 Pin Y 1
15 4110000172021 齿条LGHD9530016 Gear rack Y 1
16 4110000172020 齿轮套组件LGHD9530015 Gear sleeve Y 1
17 4110000172019 卡簧LGHD9530014 Retaining ring Y 1
18 4110001680007 盒盖LGH9530013 Cover Y 1
19 4110000172022 齿条筒LGHD9530017 Rack sleeve Y 1
20 4110000746001 软轴总成LGHD9360001 Flexible shaft Y 1
