LG944MSK 4120000064 变速操纵阀LG03-BSF(350802) Shift control valve

1 4120000064005 阀体ZL30.05.17-1 Valve body N 1

2 4015000209 YB315Z5-09组合密封垫圈30 Sealing washer Y 2

3 4120000064003 螺栓ZL30.05.17-2 Screw N 2

4 4120000064007 减压阀杆ZL30.05.17-4 Spool N 1

5 4120000064013 刹车阀杆ZL30.05.17-5a Brake lever N 1

6 4120000064002 刹车弹簧ZL30.05.17-6 Spring Y 1

7 4120000064039 标牌ZL30.05.17-27B/ Name plate N 1

8 4120000064028 弹簧ZL30.05.17-7 Spring Y 2

9 4090000120 钢球GB308-12.7-GCr15 Ball Y 2

10 4120000064024 分配阀杆ZL30.05.17-8 Frame N 1

11 4015000122 垫圈JB982-24 Washer Y 1

12 4120000064031 螺栓ZL30.05.17-10 Screw N 1

13 4120000064042 垫圈ZL30.05.17-11/2A Washer N 1

14 4030000012 O形圈GB1235-22*2.4 O-ring Y 1

15 4030000731 0形圈GB1235-30*2.4 O-ring Y 1

16 4120000064025 挡套ZL30.05.17-11 Spacer sleeve Y 1

17 4120000064043 骨架式油封18*30*7HG4-692- Lip seal N 1

18 4120000064044 防尘圈ZL30.05.17-31 Sleeve N 1

19 4015000283 挡圈GB893.1-30-65Mn Retaining ring Y 1

20 4120000064017 螺栓ZL30.05.17-19 Screw N 1

21 4120000064035 气阀座ZL30.05.17-12A Valve seat N 1

22 4120000064036 气阀杆ZL30.05.17-13B Valve rod N 1

23 4030000268 O形圈GB3452.1-17.0*1.80G O-ring Y 1

24 4030000011 O形圈GB1235-20*2.4 O-ring Y 1

25 4015000308 挡圈GB893.1-20-65Mn Retaining ring Y 1

26 4120000064037 气阀体ZL50.6.18-16a/1 Valve body N 1

27 4120000064018 螺母ZL25.1-09A Nut N 1

28 4120000064014 圆柱塞ZL30.05.17-18 Plug N 1

29 4030000634 0形圈GB1235-13*1.9 O-ring Y 1

30 4120000064001 螺栓Φ55*31 ZL30.05.17-20 Bolt Y 1

31 4015000307 垫圈JB982-42 Washer Y 1
32 4120000064011 滑块ZL30.05.17-22 Slide block N 1
33 4120000064033 圆板ZL30.05.17-26 Plate N 1
34 4090000154 钢球GB308-4.762-GCr15 Ball Y 1
35 4120000064010 弹簧ZL30.05.17-23 Spring Y 1
36 4120000064009 弹簧ZL30.05.17-24B Spring Y 1
37 4120000064041 调压垫片ZL30.05.17-25A Shim N 1
38 4120000064040 NPT1/8＂丝堵ZL30.05.17-28 Plug N 1
