LG956L 2903002885 散热器总成 Cooling system

1 29030028831 散热器进水管 Hose Y 1

2 4017000018 喉箍JB8870-d70 Clamp Y 2

3 4110002252 散热器总成LG958L-3 Radiator Y 1

4 4041001486 直接头LGB155-03036 Nipple Y 2

5 4030000211 O形圈GB3452.1-30.0*2.65G O-ring Y 2

6 4041001211 组合接头LGB143-03625 Nipple Y 2

7 4011000461 螺栓GB16674-M8*16EpZn-8.8 Bolt Y 7

8 29030010811 管夹 Clamp Y 4

9 4011000027 螺栓GB5783-M12*65EpZn-8.8 Bolt Y 4

10 4015000026 垫圈GB93-12-65Mn Spring washer Y 4

11 29330023151 垫圈12 Washer Y 4

12 29030009681 垫板 Plate Y 4

13 4041000011 分体法兰LGB117-314650 Flange half Y 3

14 4030000130 O形圈GB3452.1-47.5*3.55G O-ring Y 3

15 4011000477 螺栓GB16674-M12*35EpZn-8.8 Bolt Y 12

16 29030023751 液压油散进油管 Hose assembly Y 1

17 29030023761 液压油散回油管 Hose Y 1

18 4041001167 软管LGB165-014310 Hose Y 1

19 4041001704 软管LGB165-014340 Hose Y 1

20 4011000475 螺栓GB16674-M10*30EpZn-8.8 Bolt Y 4

21 4030000029 O形圈GB3452.1-37.5*3.55G O-ring Y 1

22 4041000027 分体法兰LGB117-312551 Flange half Y 1

23 29030000041 管夹 Clamp Y 3
