LG916 4110002442 变矩器总成370710 Torque converter system

1 4011001579 P-螺栓GB5783-M12*25-8.8 Screw N 6

2 4015000338 GB93-1987标准型弹簧垫圈12 Spring washer N 6

3 4110002138001 压板YJ280-18 Flange Y 1

4 4110002138002 弹性板YJ280B-19A Plate Y 1

5 4110002138003 弹性连接板YJ280B-20A Attaching plate Y 1

6 4110002138004 泵轮罩YJ280B-17B Cover Y 1

7 4013000031 螺母GB6170-M8EpZn-10 Nut Y 24

8 4015000036 垫圈GB93-8-65Mn Spring washer Y 24

9 4110002138028 油泵轴ⅠYJ280B-23 Shaft Y 1

10 4021000021 滚动轴承GB276-6308 Ball bearing Y 1

11 4110002138029 涡轮轴YJ280F-06 Shaft Y 1

12 4015000257 挡圈GB894.1-38-65Mn Retaining ring Y 2

13 4015000046 挡圈GB894.1-50-65Mn Retaining ring Y 1

14 4021000011 滚动轴承GB276-6010 Ball bearing Y 1

15 4110002138005 垫圈YJ280B-13.2 Washer N 1

16 4110002138006 涡轮YJ280B-13.1 Turbine Y 1

17 4110002138007 涡轮座YJ280B-13.3S Seat N 1

18 4015000133 挡圈GB894.1-55-65Mn Retaining ring Y 1

19 4110002138008 导轮YJ280B-15 Stator Y 1

20 4110002138009 O型圈290*3.55 YJ280B-14 O-ring Y 1

21 4110002138010 泵轮YJ280B-11 Impeller Y 1

22 4110002138032 O型圈GB3452.1-82-135*3.1 O-ring Y 1

23 4015000241 挡圈GB893.1-110-65Mn Retaining ring Y 1

24 4021000113 滚动轴承GB276-6212 Ball bearing Y 1

25 4110002138011 泵轮座YJ280B-9 Seat Y 1

26 4110002138033 铆钉GB867-8*20 Rivet N 10

27 4011000764 螺栓GB5783-M8*35EpZn-10.9 Bolt Y 24

28 4011000993 螺栓GB5783-M10*25EpZn-10.9 Bolt Y 8

29 4110002138034 销GB119.1-8*25 Pin Y 4

30 4110002138012 骨架油封120×100×13 Sealing ring Y 1

31 4011000763 螺栓GB5783-M10*30EpZn-10.9 Bolt Y 12

32 4015000025 垫圈GB93-10-65Mn Spring washer Y 12

33 4011001097 螺栓GB5783-M8*16EpZn-10.9 Screw Y 8

34 4015000036 垫圈GB93-8-65Mn Spring washer Y 8

35 4110002138013 盖板YJ280B-12 Plate Y 2

36 4110002138014 密封环（80）YJ280B-8 Sealing ring Y 2

37 4110002138015 中节（12孔）YJ280B-1A Cover Y 1

38 4110002138031 输出齿轮YJ280B-6 Gear Y 1

39 4015000019 挡圈GB894.1-30-65Mn Retaining ring Y 1

40 4110002138016 纸垫YJ280B-10 Gasket Y 1

41 4110002138017 主动齿轮YJ280B-3 Gear Y 1

42 4015000239 挡圈GB894.1-100-65Mn Retaining ring Y 1

43 4110002138035 螺栓GB5783-M10*95EpZn-8.8 Screw Y 4

44 4015000025 垫圈GB93-10-65Mn Spring washer Y 4

45 4110002138018 出油阀YJ265-40000 Valve Y 1

46 4110002138030 密封环（50）YJ280B-5 Sealing ring Y 1

47 4011000763 螺栓GB5783-M10*30EpZn-10.9 Bolt Y 6

48 4015000025 垫圈GB93-10-65Mn Spring washer Y 6

49 4110002138019 变矩器壳体YJ280F-01 Housing Y 1

50 4110002138020 标牌YJ280F-11 Name plate N 1

51 4110002138021 导轮座YJ280B-4 Stator housing Y 1

52 4110002138022 分油套YJ280B-7 Sleeve Y 1

53 4015000017 挡圈GB893.1-90-65Mn Retaining ring Y 1

54 4110002138023 减压阀YJ280-10000X Valve Y 1

55 4015000025 垫圈GB93-10-65Mn Spring washer Y 4

56 4011000993 螺栓GB5783-M10*25EpZn-10.9 Bolt Y 4

57 4019000007 铆钉GB867-3*6-BL2 Rivet N 4

58 4110002442001 吊怀螺钉M12×22-GB825-88 Screw N 1

59 4110002138024 螺塞GB/ZQ4448 Plug Y 1

60 4015000046 挡圈GB894.1-50-65Mn Retaining ring Y 2

1 4110002138025 油泵主动齿轮YJ280B-21 Gear Y 2
62 4021000011 滚动轴承GB276-6010 Ball bearing Y 4
63 4110002138026 轴套YJ280B-22 Sleeve Y 2
64 4110002138027 油泵轴ⅡYJ280B-24 Shaft Y 1
65 4015000015 挡圈GB893.1-80-65Mn Retaining ring Y 2
