LG916 2904001280 变矩器总成 Torque converter system

1 29030026031 滤清器支架 Bracket Y 1

2 4011000560 螺栓GB16674-M12*25EpZn-8.8 Bolt Y 2

3 4110000507 滤清器QF60M33G-1 Oil filter Y 1

4 4011000455 螺栓GB16674-M8*25EpZn-8.8 Bolt Y 4

5 29040010661 变速泵至滤清器油管 Hose assembly Y 1

6 4190000343 喉箍JB8870-d16 Clamp Y 2

7 29040010691 滤清器至变矩器油管 Hose assembly Y 1

8 4041001262 组合接头LGB143-03019 Nipple Y 1

9 29040012851 变速泵吸油管 Hose assembly Y 1

10 4120000388 胶管JB8406-B10*800 Hose assembly Y 1

11 4041001063 组合接头LGB143-01810 Nipple Y 1

12 4041001420 软管LGB125-005144 Hose assembly Y 1

13 4120006392 胶管JB8406-B19*400 Hose Y 1

14 29040008781 接头体 Nipple Y 1

15 4017000011 喉箍JB8870-d32 Clamp Y 4

16 29040008791 接头体 Nipple Y 1

17 29040008311 三通接头 Three-way nipple Y 1

18 4011000084 螺栓GB5783-M10*30EpZn-8.8 Bolt Y 12

19 4015000025 垫圈GB93-10-65Mn Spring washer Y 12

20 29370018071 接头体 Nipple Y 1

21 4110002442 变矩器总成YJ280F－Ⅱ Torque converter Y 1

22 4120000175 胶管JB8406-B19*800 Hose assembly Y 1

23 29040010121 接头 Joint Y 1

24 4011000461 螺栓GB16674-M8*16EpZn-8.8 Bolt Y 1

25 29350000021 管夹 Hose clamp Y 1

26 29040008271 接头体 Nipple Y 2

27 4030000013 O形圈GB1235-32*3.1 O-ring Y 2

28 4041001211 组合接头LGB143-03625 Nipple Y 1
