E635F 4110002578 进气歧管 Suction manifold

1 4110002578061 管129005-03080 Intake bend Y 1
2 4110001600033 管夹129410-03990 Clamp Y 2
3 4110002578062 进气歧管129602-12101 Inlet manifold Y 1
4 4110002578063 垫片129407-12110 Gasket Y 1
5 4110000129034 螺栓M8X20 26106-080202 Screw Y 6
6 4110000129102 螺栓M8X80 26106-080802 Screw Y 1
7 4110002578064 接头129486-12581 Nipple Y 1
8 4110002578065 垫片129150-77511 Gasket Y 1
9 4110000129034 螺栓M8X20 26106-080202 Screw Y 4
