LG918 4110000218 前进低档离合器(370804) Shaft and clutch assembly

1 7200000264 前进低挡离合器BD05-01000 Clutch Y 1
2 4021000190 止动环GB305-80/86.6 Retaining ring Y 2
3 4021000170 P轴承GB276-6208N Ball bearing Y 2
4 4110000218028 挡圈BD05-01001 Retaining ring Y 1
5 4015000046 挡圈GB894.1-50-65Mn Retaining ring Y 2
6 4110000218016 齿轮BD05-01002 Gear Y 2
7 4110000218023 弹簧支承座BD05-01010 Spring seat Y 2
8 4110000218077 离合器弹簧BD05-01005 Spring Y 2
9 4015000300 挡圈GB893.1-150-65Mn Retaining ring Y 2
10 4110000218078 离合器活塞压板BD05-01003 Anchor plate Y 2
11 4110000218036 垫板BD05-01004 Washer Y 8
12 4110000218095 磨擦片BD05-01300 Friction disc Y 8
13 4030000035 O形圈GB3452.1-53.0*5.30G O-ring Y 2
14 4110000218068 活塞BD05-01101 Cylinder piston Y 2
15 4110000218094 密封环BD05-01103 Spacer ring Y 2
16 4110000218096 前进低档离合器壳体BD05-01200 Converter housing Y 1
17 4110000960002 螺塞07043-70108 Plug Y 2
18 4110000218017 齿轮BD05-01006 Gear Y 1
19 4110000218093 密封环BD05-01008 Spacer ring Y 3
20 4021000009 滚动轴承GB276-6008 Ball bearing Y 2
21 4015000199 挡圈GB893.1-68-65Mn Retaining ring Y 2
22 4110000218024 挡环BD05-01007 Retaining ring Y 1
23 4021000021 滚动轴承GB276-6308 Ball bearing Y 2
24 4110000218025 挡环BD05-01009 Retaining ring Y 1
25 4110000218029 挡圈BD05-01012 Retaining ring Y 1
