B876F Q1900-2620000387 多功能斗1.0×2350 Bucket assembly

1 26200004041 前铲斗装配 Bucket N 1

2 26200004341 后铲斗 Bucket Y 1

3 4013000370 螺母GB6170-M10flZnyc-8-480 Nut Y 8

4 4011001481 螺栓GB5782-M10*110flZnyc-8.8-480 Screw Y 2

5 4043000374 垫片LGB303-45*80*1 Shim Y 4

6 4043000629 垫片LGB303-45*65*1 Shim Y 6

7 26190001562 转斗缸前销 Pin Y 2

8 4015000021 挡圈GB894.1-45-65Mn Retaining ring Y 2

9 26200000941 中销 Pin Y 2

10 26200000981 轴套 Bushing Y 2

11 4043000628 垫片LGB303-50*85*1 Shim Y 4

12 26200000951 下销 Pin Y 2

13 4011001354 螺栓GB5782-M10*90flZnyc-8.8-480 Screw Y 2

14 4030000065 油杯JB7940.1-M10*1 Lubricating nipple Y 2
