B876F C0543-4110003513 变速箱壳体总成4661.101.028 Transmission assembly

1 4110003513008 变速箱体4661.301.049 Housing N 1
2 4110003513009 管4661.301.093 Tube N 1
3 4110003513019 销0631.306.174 Pin N 1
4 4110003513038 铭牌0501.320.482 Name plate N 1
5 4110003513039 铭牌0501.316.442 Name plate N 1
6 4110003513040 铭牌0730.365.288 Name plate N 1
7 4110003513041 铭牌0501.329.234 Name plate N 1
8 4110003513042 堵头0501.214.641 Plug N 1
9 4110003513043 堵头0636.302.602 Plug N 2
10 4110003513044 O型圈0634.100.633 O-ring N 2
11 4110003513045 喷嘴4661.301.029 Nozzle N 1
12 4110003513046 喷嘴4661.301.027 Nozzle N 1
13 4110003513047 喷嘴4661.301.041 Nozzle N 1
14 4110003513048 喷嘴4661.301.062 Nozzle N 1
15 4110003513049 堵头4660.201.008 Plug N 37
16 7200001705 O形圈(8*1.5)0634303280 O-ring Y 37
17 4110003513050 堵头0636.100.117 Plug N 6
18 4110003513051 油底壳4661.305.025 Oil pan N 1
