LG956L A0300-2903002937 散热器总成 Cooling system

1 4011000475 螺栓GB16674-M10*30EpZn-8.8 Bolt Y 4

2 4030000029 O形圈GB3452.1-37.5*3.55G O-ring Y 1

3 4041000027 分体法兰LGB117-312551 Flange half Y 1

4 4011000458 螺栓GB16674-M8*20EpZn-8.8 Bolt Y 3

5 29030000041 管夹 Clamp Y 3

6 4011000477 螺栓GB16674-M12*35EpZn-8.8 Bolt Y 12

7 4030000130 O形圈GB3452.1-47.5*3.55G O-ring Y 3

8 4041000011 分体法兰LGB117-314650 Flange half Y 3

9 29030021761 膨胀水箱总成 Expansion tank N 1

10 4110002851 散热器总成LY-LG956-8 Radiator Y 1

11 29030014331 接头体 Nipple Y 2

12 4030000211 O形圈GB3452.1-30.0*2.65G O-ring Y 2

13 4011000284 螺栓GB5783-M12*60EpZn-8.8 Screw Y 4

14 4015000026 垫圈GB93-12-65Mn Spring washer Y 4

15 29330023151 垫圈12 Washer Y 4

16 29030014551 散热器回油胶管 Hose assembly Y 1

17 4041001036 软管LGB165-014250 Hose assembly Y 1

18 4041001152 软管LGB165-014265 Hose assembly Y 1

19 29030009531 散热器进油胶管 Hose assembly Y 1
