L978F 驾驶室内置电气 Cab electric system P4300-2943000378

1 4190001839 扎丝LG13-ZS4*160 Cable tie Y 30

2 29370015871 收音机总成 Radio Y 1

3 4130000700 点烟器插头8EZ008022-011 Cigarette lighter Y 1

4 4130001413 室内灯24-6212-24V Lamp Y 1

5 4014000519 螺钉GB818-M5*20flZnyc-4.8-480 Screw Y 6

6 4015000431 垫圈GB97.1-5flZnyc-300HV-480 Washer Y 6

7 4190000608 电风扇 Fan Y 1

8 4014000529 螺钉GB818-M6*35flZnyc-4.8-480 Screw Y 3

9 4015000424 垫圈GB97.1-6flZnyc-300HV-480 Washer Y 7

10 29370022472 驾驶室线束 Wiring harness N 1

11 4130001842 手制动开关ZB4-BS52 Button N 1

12 4130002790 GPS终端BOSTON3-2.0 Control unit Y 1

13 4130002691 键盘BOSTON3_KEYBOARD10 Keyboard Y 1

14 4014000058 螺钉GB70.1-M6*20EpZn-8.8 Screw Y 2

15 29430003802 仪表台线束 Wiring harness Y 1

16 4190000020 扎丝LG13-ZS4*250 Cable tie Y 20

17 4130001700 中央电器控制盒CECB-8 Control box Y 1

18 4013000372 螺母GB6170-M6flZnyc-8-480 Nut Y 4

19 4130001855 保险丝电路标识 Decal Y 1

20 4011001297 螺栓GB16674.1-M8*16flZnyc-8.8-480 Screw Y 5

21 4014000523 螺钉GB818-M5*16flZnyc-4.8-480 Screw Y 4

22 29370024041 固定板 Plate Y 1

23 4015000432 垫圈GB97.1-4flZnyc-300HV-480 Washer Y 4

24 4013000377 螺母GB6170-M5flZnyc-8-480 Nut Y 4

25 29370024712 支板 Plate Y 1
