L978F 先导操纵电气总成 Servo pipe electric system P4110-2941000083

1 29410000282 接近开关线束 Wiring harness Y 1

2 4190001838 扎丝RTGB-370HD-S Cable tie Y 14

3 4130001028 接近开关J7-D10B1/DC Position switch Y 2

4 4130001006 CLIP 1027-003-1200 Clip Y 2

5 29140012881 放平限位支架 Bracket Y 1

6 4015000433 垫圈GB97.1-10flZnyc-300HV-480 Washer Y 2

7 4013000370 螺母GB6170-M10flZnyc-8-480 Nut Y 2

8 4011001300 螺栓GB16674.1-M10*30flZnyc-8.8-480 Screw Y 2

9 4015000428 垫圈GB97.1-12flZnyc-300HV-480 Washer Y 2

10 29140016461 举升限位支架 Bracket Y 1

11 4011001241 螺栓GB5783-M12*25flZnyc-8.8-480 Screw Y 2

12 4015000425 垫圈GB96.1-8flZnyc-300HV-480 Washer Y 1

13 4011001247 螺栓GB5783-M8*20flZnyc-8.8-480 Screw Y 1

14 14400342 扎带 Strip clamp Y 5

15 4011001296 螺栓GB16674.1-M8*20flZnyc-8.8-480 Screw Y 5

16 4041002410 管夹LGB169-A12*10 Clamp Y 3

17 4011001297 螺栓GB16674.1-M8*16flZnyc-8.8-480 Screw Y 3
