LG968N 散热器总成(320204) Radiator assembly A0394-4110002286

1 4110002286001 水散热器S9110798B Radiator Y 1

2 4110002025002 液压油散热器S9110745A Radiator Y 1

3 4110002286002 左框架部件KB0255 Framework N 1

4 4110002286003 右框架组合KB0256 Framework N 1

5 4110002286004 下框架330084 Framework N 1

6 4110002286005 导风罩部件DB0075 Fan shroud N 1

7 4110002025008 护网部件HB0047 Hood Y 2

8 4110002286006 挡风板A330256 Wind deflector N 1

9 4110002025010 下挡风板330080 925*181*2 Wind deflector Y 1

10 4110002025011 硬橡胶减震垫720007 100*80*16 Damper mat N 4

11 4110002025012 蒸汽管∮8 L=1000mm 8010081000 Rubber pipe Y 1

12 4110002286007 卡箍990002 Clamp N 2

13 4110002025013 蒸汽管∮8 L=800mm 8010080800 Rubber pipe Y 1

14 4110002286008 旋转支架QB0396 Radiator bracket N 1

15 4110002035002 旋转支架开关QB0147 Lock Y 2

16 4110002286009 传动油散S9111381C Oil cooler N 1

17 4110002025015 法兰面螺栓614243 M8*30 镀蓝白锌 Bolt N 44

18 4110002025016 不锈钢大垫片631330 ∮8不锈钢 Washer N 28

19 4013000363 螺母GB6170-M8-EpZn-8 Nut N 28

20 4011000277 螺栓GB16674-M8*40EpZn-8.8 Bolt Y 6

21 4011001300 螺栓GB16674.1-M10*30flZnyc-8.8-480 Screw Y 4

22 4015000197 垫圈GB96.1-10EpZn-300HV Washer Y 4

23 4011001371 螺栓GB16674.1-M12*35flZnyc-10.9-480 Bolt Y 6

24 4110002025019 不锈钢大垫片631530 ∮12不锈钢 Washer N 6

25 4013000011 螺母GB6170-M12EpZn-8 Nut Y 2

26 4110002025021 “U”型卡条829002 2*9*12.5 Sealing strip N 1

27 4110002025020 “U”型密封条829001 2*12*26 Sealing strip N 1

28 4110002115 Ⅱ型90Kpa双层密封加水口盖 Cap N 1
