L952D 动臂油缸（3713CH) Lifting cylinder F1310-4120007287

1 4120007287001 缸筒总成24A140570 Cylinder tube Y 1

2 4120007287002 活塞杆总成24A114910 Piston rod Y 1

3 4120007287003 缸盖24C101100 Cover Y 1

4 4120004336015 衬套24S290401 Bushing Y 1

5 4120005980008 钢丝挡圈-孔用24C090220 Retaining ring Y 1

6 4120005999004 密封件-缓冲24H009004 Sealing ring N 1

7 4120005999005 密封件-活塞杆24F209003 Sealing ring N 1

8 4120005999006 挡圈-U形圈24E009025 Retaining ring N 1

9 4120004336016 密封件-防尘24D209002 Sealing ring N 1

10 4120005980009 钢丝挡圈-孔用24C090240 Retaining ring Y 1

11 4120006611003 O形圈24K11500A O-ring N 1

12 4120006611004 挡圈-O形圈24M11600D O-ring N 1

13 4120006611005 O形圈24K315761 O-ring N 1

14 4120006611006 活塞24C102080 Piston Y 1

15 4120005999013 O形圈24K10900A O-ring N 1

16 4120005999014 挡圈-O形圈24M30950A O-ring N 1

17 4120006611007 密封件-活塞24P216002 Sealing ring N 1

18 4120006611008 支承环24G216051 Sealing ring N 2

19 4120005980011 活塞背母24C103050 Nut Y 1

20 4090000168 钢球GB308-5-GCr6 Ball Y 1

21 4120005685008 螺钉-内六角凹端紧定24T908161 M8*16L Screw Y 1

22 4120006611010 螺钉-内六角圆柱头24T516755 Screw Y 12

23 4120005685012 固定座24C003020 M16 Anchorage Y 1

24 4120007287004 密封件包24A103660S Sealing kit Y 1
