L952D 举升缸总成 Lift cylinder F1300-2913002255

1 4120007287 动臂油缸HSGF-160*90*894-450 Lifting cylinder Y 2

2 29130023271 右动臂缸小腔钢管 Pipe Y 1

3 4030000026 O形圈GB3452.1-32.5*3.55G O-ring Y 4

4 4011001298 螺栓GB16674.1-M10*55flZnyc-8.8-480 Screw Y 8

5 4011001288 螺栓GB16674.1-M10*50flZnyc-8.8-480 Screw Y 8

6 4015000433 垫圈GB97.1-10flZnyc-300HV-480 Washer Y 8

7 4011001248 螺栓GB5783-M10*25flZnyc-8.8-480 Screw Y 4

8 4041001017 U形螺栓LGB159-13040 U-bolt Y 2

9 4041001018 底板LGB160-3040 Bracket Y 4

10 4013000370 螺母GB6170-M10flZnyc-8-480 Nut Y 8

11 29130022591 右动臂缸大腔钢管 Pipe Y 1

12 4041001909 软管LGB127-412132 Hose assembly Y 2

13 4041002615 软管LGB127-412120 Hose assembly Y 2

14 29130022611 举升联三通钢管 Pipe Y 2

15 4030000029 O形圈GB3452.1-37.5*3.55G O-ring Y 2

16 4011001300 螺栓GB16674.1-M10*30flZnyc-8.8-480 Screw Y 8

17 29130022621 左动臂缸大腔钢管 Pipe Y 1

18 29130023291 左动臂缸小腔钢管 Pipe Y 1
