L956F 多路阀KM300-II-19A部装总成 Control valve assembly F1210-2912002949

1 4120006636 多路阀KM300-II-19A Control valve Y 1

2 4030000029 O形圈GB3452.1-37.5*3.55G O-ring Y 2

3 29120020701 多路阀进油钢管 Pipe Y 1

4 4011001281 螺栓GB5782-M12*55flZnyc-8.8-480 Screw Y 2

5 4011001520 螺栓GB5782-M12*65flZnyc-8.8-480 Screw Y 2

6 4015000428 垫圈GB97.1-12flZnyc-300HV-480 Washer Y 8

7 4041000133 直接头LGB120-01414 Nipple Y 5

8 4041000767 O形圈LGB168-11124 O-ring Y 9

9 4190000204 三通接头ET08LOMDA3C Three-way nipple Y 1

10 4041000604 直接头LGB120-01614 Nipple Y 2

11 4041001023 组合接头LGB143-01608 Nipple Y 2

12 4030000240 O形圈GB3452.1-8.00*1.80G O-ring Y 2

13 4030000530 O形圈GB3452.1-6.00*1.80G O-ring Y 3

14 4041001047 组合接头LGB143-01406 Nipple Y 3

15 4011001510 螺栓GB16674.1-M12*35flZnyc-8.8-480 Screw Y 4

16 29120019571 多路阀支架 Bracket Y 1

17 4011001585 螺栓GB5782-M10*80flZnyc-10.9-480 Bolt Y 3

18 4015000433 垫圈GB97.1-10flZnyc-300HV-480 Washer Y 6

19 4013000370 螺母GB6170-M10flZnyc-8-480 Nut Y 3

20 4011001468 螺栓GB16674.1-M14*35flZnyc-8.8-480 Bolt Y 4

21 4011001432 螺栓GB16674-M10*20flZnyc-8.8-480 Screw N 2

22 29120019601 管夹 Clamp Y 1

23 29120019561 多路阀固定板 Valve plate Y 1

24 29120019611 固定板 Plate Y 1

25 4011001300 螺栓GB16674.1-M10*30flZnyc-8.8-480 Screw Y 2

26 29120033221 多路阀回油钢管 Pipe Y 1

27 4011001355 螺栓GB5782-M12*70flZnyc-8.8-480 Screw Y 4

28 4041000774 螺塞LGB135-01422 Plug Y 2
