L956F多路阀KM300-II-19A（370142） Control valve assembly F1205-4120006636

1 4120006566001 端盖2022000018 End cover N 2

2 4120006566002 过载阀2022000035 Valve N 1

3 4120006566003 阀体2022000062 Valve body N 1

4 4120006566004 阀座2022000032 Valve seat N 1

5 4120006566005 阀体2022000022 Valve body N 1

6 4120006566006 卸荷阀总成2022000047 Valve N 1

7 4120006566007 阀座2022000019 Valve seat N 2

8 4120006566008 动臂联端盖2022000003 End cover N 1

9 4120006566009 动臂联阀杆2022000015 Valve rod N 1

10 4120006566010 转斗联阀杆2022000016 Valve rod N 1

11 4120006566011 隔套2022000013 Spacer sleeve N 2

12 4120006566012 转斗联端盖2022000007 End cover N 1

13 4120006566013 活塞2022000004 Piston N 1

14 4120006566014 弹簧2022000005 Spring N 1

15 4120006566015 盖2022000006 End cover N 1

16 4120006566016 阀块2022000052 Valve block N 1

17 4120006566017 挡圈2022000051 Retaining ring N 1

18 4013000260 P-螺母GB6173-M24*2-05 Nut gb6173-m24*2-05 Y 1

19 4120006566018 过载阀2022000036 Valve N 1

20 4120006566019 过载阀2022000049 Valve N 1
