L936 水油散热器总成L936-3F(43305) Radiator A0390-4110003565

1 4110003565001 液压油散S9113457C Hydraulic oil cooler Y 1

2 4110003565002 水散热器S9113457B Raditaor Y 1

3 4110003565003 中冷器S9113457A Charge air cooler Y 1

4 4110003565004 上钢架KB0588 Cover plate N 1

5 4110003565005 下钢架KB0589 Radiator bracket N 1

6 4110003565006 导风罩DB0620 Fan shroud Y 1

7 4110003565007 挡风板330623 Wind deflector N 1

8 4110003565008 U型密封条8290023180 Sealing strip N 1

9 4110003565009 防护网BHB0314 Fan guard Y 1

10 4110003565010 防护网AHB0313 Fan guard Y 1

11 4110003296206 减震垫720056 Rubber mat N 1

12 4110002945007 放水阀739001 Valve Y 1

13 4110002286007 卡箍990002 Clamp N 2

14 4110002506023 放水管8000080800 Hose Y 1

15 4110003075021 锁扣安装轴330530 Shaft N 2

16 4110003075020 锁扣橡胶垫720044 Rubber mat N 2

17 4110003075022 锁扣定销330531 Pin N 2

18 4110003075023 锁扣弹性环330532 Clamp N 2

19 4110003565011 传动油散S9113526D Oil cooler Y 1

20 4110003565012 旋转支架KZ9113457 Radiator bracket Y 1

21 4110001929 Ⅱ型90Kpa复式加水口盖FG2 Cap Y 1
