L936 变矩器总成 Torque converter system B0400-2904001425

1 29040014261 变速泵至滤清器油管 Hose Y 1

2 29050018471 接头体 Nipple Y 2

3 4030000013 O形圈GB1235-32*3.1 O-ring Y 2

4 4110000507 滤清器QF60M33G-1 Oil filter Y 1

5 29040001031 滤清器至变速箱油管 Hose assembly Y 1

6 4011000527 螺栓GB16674-M8*45EpZn-8.8 Bolt Y 2

7 4011000481 螺栓GB16674-M8*30EpZn-8.8 Bolt Y 6

8 4030000279 O形圈GB3452.1-25.0*3.55G O-ring Y 1

9 4011000475 螺栓GB16674-M10*30EpZn-8.8 Bolt Y 8

10 4030000024 O形圈GB3452.1-26.5*2.65G O-ring Y 2

11 29040007741 压盖 Cover Y 2

12 29040007531 钢管 Tube Y 1

13 29040007581 变速泵吸油管 Hose assembly Y 1

14 29040012891 滤清器支架 Bracket Y 1

15 4011000560 螺栓GB16674-M12*25EpZn-8.8 Bolt Y 2

16 4011000091 螺栓GB5783-M12*40EpZn-8.8 Bolt Y 12

17 4015000026 垫圈GB93-12-65Mn Spring washer Y 12
