G9165 2801000860 上盖板总成 Cover plate assembly

1 4015000197 垫圈GB96.1-10EpZn-300HV Washer Y 10

2 4011000084 螺栓GB5783-M10*30EpZn-8.8 Bolt Y 6

3 28010008631 海绵A Sponge Y 1

4 28010008621 密封垫 Gasket Y 1

5 4011000081 螺栓GB5783-M10*20EpZn-8.8 Bolt Y 12

6 4015000162 垫圈GB97.1-10EpZn-300HV Washer Y 8

7 4017000044 喉箍JB8870-d160 Clamp Y 2

8 28010008761 空滤进气胶管 Hose Y 1

9 28010008641 海绵B Sponge Y 1

10 28010008611 上盖板焊接 Cover plate Y 1

11 4015000198 垫圈GB96.1-6EpZn-300HV Washer Y 8

12 4013000211 螺母GB889.1-M6EpZn-8 Nut Y 8

13 4043001460 卡子胶条LGB320-U160 Sealing strip Y 8

14 28010011281 透气管 Hose Y 1

15 4017000011 喉箍JB8870-d32 Clamp Y 2

16 4120001088 换气过滤器L1.0807-31 Breather cap Y 1

17 28010011221 安装座 Seat Y 1

18 4015000168 垫圈GB97.1-12EpZn-300HV Washer Y 6

19 4011000091 螺栓GB5783-M12*40EpZn-8.8 Bolt Y 6

20 28010010291 连接管 Intermediate pipe Y 1

21 4043001002 卡子胶条LGB320-U420 Sealing strip Y 2

22 4110001754 排气尾管 Pipe Y 1
