LG952N 4120007608 转斗油缸HSGF-18090548-1043(3713CH) Tilt cylinder

1 4120007608001 缸筒总成 24A141350 Cylinder tube Y 1
2 4120007577002 活塞杆总成24A115200 Piston rod Y 1
3 4120007608002 缸盖 24C101260 Cover Y 1
4 4120005980010 衬套24S290501 Bushing Y 1
5 4120005980008 钢丝挡圈-孔用24C090220 Retaining ring Y 1
6 4120005999004 密封件-缓冲24H009004 Sealing ring N 1
7 4120005999005 密封件-活塞杆24F209003 Sealing ring N 1
8 4120005999006 挡圈-U形圈24E009025 Retaining ring N 1
9 4120005999007 密封件-防尘24D209001 Sealing ring N 1
10 4120005980009 钢丝挡圈-孔用24C090240 Retaining ring Y 1
11 4120005998008 O形圈24K11700A O-ring N 1
12 4120005998009 挡圈-O形圈24M11800D O-ring N 1
13 4120007608003 O形圈 24K317761 O-ring N 1
14 4120006998002 活塞24C102200 Piston Y 1
15 4120005998012 密封件-活塞24P218002 Sealing ring N 1
16 4120005999013 O形圈24K10900A O-ring N 1
17 4120005999014 挡圈-O形圈24M30950A O-ring N 1
18 4120005998015 支承环24G218041 Sealing ring N 2
19 4120005980011 活塞背母24C103050 Nut Y 1
20 4090000168 钢球GB308-5-GCr6 Ball Y 1
21 4120005685008 螺钉-内六角凹端紧定24T908161 M8*16L Screw Y 1
22 4120005980012 轴套24C116170 Bushing Y 1
23 4120006998003 销边防尘24R309520 Sealing ring N 4
24 4120005980007 轴套24C117170 Bushing Y 1
25 4120006560024 螺钉-内六角圆柱头24T520805 Screw Y 12
26 4120005801013 油杯24V2100A1 M10x1 Grease cup N 1
27 4120007608004 密封件包 24A103970S Sealing kit Y 1
