LG944MSK 2909001177001 后桥主传动 Rear final drive assembly

1 2907002025063 输入法兰 12D0021 Flange Y 1

2 2907002025064 锁紧螺母 34C0608 Lock nut Y 1

3 2907002025065 油封 13B0169 Sealing ring Y 1

4 2907002025066 密封盖 53A0308 Sealing cover Y 1

5 2907002025029 垫圈 06B0008 Washer Y 1

6 2907002025067 螺栓 01B0036 Bolt Y 1

7 2907002025068 垫密片 81A0037 Liner shim Y 1

8 2907002025069 垫片28C0196 Washer N 1

9 2909001177005 托架总成 41C1933 Center housing Y 1

10 2907002025071 轴承套 55A0218 Bearing bushing Y 1

11 2907002025072 轴套51C0238 Bushing N 1

12 2907002025073 圆锥滚子轴承31311 23B0018 Needle bearing Y 2

13 2909001177006 主动螺旋锥齿轮 43A0140 Angle gear N 1

14 2909001177007 大螺旋锥齿轮43A0152 Angle gear N 1

15 2907002025077 圆柱滚子轴承92606E 22B0001 Bearing Y 1

16 2907002025078 挡圈 07B0027 Retaining ring Y 1

17 2907002025080 A型限滑差速器总成 41C0110 Differential side gear Y 1

18 2907002025081 调整螺母 03B0130 Nut Y 2

19 2907002025082 圆锥滚子轴承32215 23B0017 Bearing Y 2

20 2907002025083 螺栓 02B0032 Bolt Y 4

21 2907002025084 淬硬垫圈 06B0270 Washer Y 4

22 2907002025085 铁丝 40B0006 Iron wire Y 2

23 2907002025086 锁紧片 21A0040 Lock washer Y 2

24 2907002025087 螺栓 02B0012 Bolt Y 2

25 2907002025014 垫圈 06B0002 Washer Y 2

26 2907002025088 螺栓 60A1028 Bolt Y 12

27 2907002025089 螺母 03V0537 Nut Y 12

28 2907002025007 淬硬垫圈 06B0214 Washer Y 12

29 2907002025091 O形圈 12B0105 O-ring Y 1

30 2907002025092 螺栓 00B0275 Bolt Y 8

31 2907002025043 垫圈 06B0013 Washer Y 8
