LFT18 4120007322 先导阀总成PCL402-4MBM3H3B-C（120101） Control lever assembly

1 4120007323001 螺钉M5X20 CL0211120803 Screw N 4

2 4120007323002 螺钉M5X12 CL0211196211 Screw N 4

3 4110000186589 螺母GB/T6170-M10 Nut N 2

4 4120007008017 10平垫GB/T97.1 Washer Y 2

5 4120007323004 压盘分总成CL3767990 Plate N 2

6 4120007322001 螺母M5 CL02612107 Nut N 7

7 4120007323006 垫圈CL3768001 Washer N 3

8 4120007323007 锚板分总成CL3768059 Plate N 3

9 4120007323008 接触销CL91271118 Pin N 1

10 4120007323009 电磁铁CL91271127 Magnet N 3

11 4120007323010 垫片CL91271122 Shim N 6

12 4120007323011 电磁铁托架CL3767922 Plate N 3

13 4014000475 P-螺钉GB70.1-M4*10EpZn-8.8 Screw Y 3

14 4015000302 垫圈GB96.1-4EpZn-300HV Washer Y 3

15 4013000122 P-螺母GB6172.1-M6EpZn-05 Nut Y 1

16 4120007322002 弹性螺钉CL3764809 Screw N 1

17 4120007323013 堵塞VSTI10X1.ORCF Plug Y 1

18 4120007323014 堵塞VSTI14X1.5ORCF Plug Y 1

19 4120007322003 螺柱CN221200032 Stud N 1

20 4120007322004 螺柱CN221200031 Stud N 2

21 4120007323017 阀体CL91223818-04 Valve body N 1

22 4120007323018 阀体CL91223251-04 Valve body N 1

23 4120007323019 O形圈CL066636127 O-ring N 2

24 4120007323020 连接板CN221200122 Plate N 1

25 4120007323023 操作杆CL91271126 Adjusting bar N 1

26 4120007323022 手柄球CL3766896 Handle ball N 2

27 4120007323021 操作杆CL91271123 Adjusting bar N 1

28 4120007323024 螺钉M4X20 CL91257024 Screw N 8

29 4016000410 P-销GB879.2-3*8 Spring pin Y 6

30 4120007323025 连接器总成CN221200022 Tool N 1

31 4120007323026 柱塞分总成CL9121590137 Piston N 4
32 4120007323027 阀杆分总成CN221200052 Valve rod N 4
33 4120007323028 弹簧CL91283768 Spring N 4
34 4120003693022 标牌CN221200047 Name plate N 1
