LG956L 2902001741 燃油箱总成 Fuel tank system

1 29020017571 燃油箱总成 Fueltank N 1

2 4011000925 螺栓GB5782-M20*110EpZn-8.8 Screw N 4

3 4015000187 垫圈GB96.1-24EpZn-300HV Washer Y 1

4 4013000042 螺母GB6171-M24*2EpZn-8 Nut Y 1

5 4015000031 垫圈GB93-24-65Mn Spring washer Y 1

6 4011000567 螺栓GB5785-M24*2*80EpZn-8.8 Bolt Y 1

7 4014000088 螺钉GB818-M5*16EpZn-4.8 Screw Y 5

8 4130001908 油位传感器RG2266型-M85 Fuel level sensor Y 1

9 4015000110 垫圈GB97.1-5EpZn-300HV Washer Y 5

10 29020006851 垫片 Spacer Y 1

11 29070016891 隔套 Casing Y 4
