G9190 4130002699 蒸发器GKZ33-5.0P3(330112) Evaporator

1 4130002699001 制冷器GKZ33-5.0H-10 Refrigerating unit Y 1

2 4190002826 换热器芯体组件 Cell core Y 1

3 4130002699002 护孔圈GKZ33-5.0H-05 Casing Y 1

4 4190002843 蒸发风机 Fan Y 1

5 4130002699003 固定锁式束线带T6109 Cable tie Y 1

6 4130002699004 自攻螺丝GB845-85 ST4.2*32 Screw Y 3

7 4130002699005 蒸发器线束GKZ33-5.0H-110 Wiring harness Y 1

8 4130002699006 下壳总成GKZ33-5.0H-40 Closure Y 1

9 4130002699007 上壳总成GKZ33-5.0H-50 Closure Y 1

10 4011001218 螺栓GB5783-M5*16EpZn-8.8 Screw Y 3

11 4110000499203 弹簧垫圈5 GB93-87 Spring washer N 3

12 4015000110 垫圈GB97.1-5EpZn-300HV Washer Y 3

13 4130002699008 线扎T6103 Cable tie Y 7

14 4130002699009 管夹体1MKL9-3.0-07 Clamp Y 2

15 4190002123012 螺栓GB5787-86 M6%x16 Y 1

16 4130002699010 卡扣GKZ33-5.0H-09 Clip Y 9

17 4130000415002 感温探头TB6502 Temperature sensor Y 1

18 4130002699011 挡风板GKZ33-5.0H-60 Bracket Y 1

19 4130002699012 十字沉头螺栓GB819-85 M5*16 Screw Y 4

20 4190003468 排水管组件 Water pipe Y 1

21 4130002699013 铜丝T6149-1 Wiring harness N 80
