LG916 4110002139 轮边减速器总成 Hub reduction

1 4110002139036 刹车盘ZL16-03-1 Brake disc Y 2

2 4110002139046 螺栓M12*1.25*35 Screw Y 56

3 4110002139037 轮毂ZL16-03-2 Hub Y 2

4 4110002139047 轮胎螺栓M18*1.5 Screw Y 16

5 4110002139038 油堵M20*1.5 Plug Y 4

6 4110002139039 行星轮架总成ZL16-03-3 Planet gear kit Y 2

7 4110002139040 边盖ZL16-03-4 Cover Y 2

8 4110002139048 螺栓M8*1.25*20 Screw Y 16

9 4110002139041 太阳轮ZL16-03-5 Sun gear Y 2

10 4015000020 挡圈GB894.1-35-65Mn Retaining ring Y 2

11 4110002139043 大帽ZL16-03-7 Sleeve Y 2

12 4110002139044 齿圈ZL16-03-8 Gear ring Y 2

13 4021000208 滚动轴承GB297-32014 Roller bearing Y 2

14 4021000228 滚动轴承GB297-30215 Bearing Y 2

15 4110002139054 油封HG4-338-66J-140*115*12 Sealing ring Y 1

16 4110002139050 弹垫φ12 Spring washer Y 56

17 4110002139051 螺母M18 Nut Y 16

18 4110002139052 弹垫φ8 Spring washer Y 16

19 4110002139055 O型圈GB/T3452-1992-298*3.5 O-ring N 2

20 4110002139028 行星轮架ZL16-03-3-1 Planet carrier Y 2

21 4110002139029 行星轮ZL16-03-3-3 Planet gear Y 6

22 4110002139030 行星轮垫ZL16-03-3-2 Washer Y 12

23 4090000126 钢球GB308-5-GCr15 Ball Y 6

24 4090000002 滚针GB309-3*29.8-GCr15 Needle roller Y 174

25 4110002139031 行星轮轴ZL16-03-3-4 Planet gear shaft Y 6
