LG918 2934003951 左电瓶箱 Battery box

1 29340036591 左电瓶箱 Battery box Y 1
2 29340011901 走线胶套 Rubber sleeve Y 1
3 29340039531 电瓶固定总成 Bracket Y 1
4 4011000485 螺栓GB16674-M1620EpZn-8.8 Screw Y 4

5 29310000091 橡胶套 Rubber sleeve Y 1

6 4014000023 螺钉GB818-M510EpZn-4.8 Screw Y 1
7 4015000110 垫圈GB97.1-5EpZn-300HV Washer Y 1
8 4190000025 扣锁NBxs1013 Lock Y 1
9 29340036601 左电瓶箱焊接总成 Battery box N 1
10 4011000866 P-螺栓GB5783-M6*10EpZn-8.8 Screw Y 1
11 4015000198 垫圈GB96.1-6EpZn-300HV Washer Y 1
12 29340029251 拉杆 Pull rod N 1
13 4013000033 螺母GB6170-M8EpZn-8 Nut Y 4
14 26330006531 缓冲器 Rubber block Y 2
15 29340006831 侧胶垫 Rubber mat Y 2
16 4015000036 垫圈GB93-8-65Mn Spring washer Y 2
17 4015000072 垫圈GB97.1-8EpZn-300HV Washer Y 2
18 29340006931 锁紧角钢 Corner steel Y 1
19 29340006841 锁紧镙杆 Bolt Y 2
20 29340006821 下胶垫 Rubber mat Y 2
