E635F 4110002578 齿轮箱 Gear housing

1 4110002578014 壳体总成719803-01500 Gear housing Y 1
2 4110002578015 油封119934-01800 Sealing ring Y 1
3 4110002578016 法兰盘119803-01520 Pump cover Y 1
4 4110002578017 螺栓119802-01561 Screw Y 3
5 4110000129038 盖124160-01751 Filler cap Y 1
6 4110000129040 盖124240-01871 Pump cover Y 1
7 4110002578018 管129795-01950 Lubricating pipe Y 2
8 4110002578019 O型圈119609-32040 O-ring Y 2
9 4110002578020 O型圈121850-51960 O-ring Y 1
10 4110000129161 密封垫圈8S 22190-080002 Washer Y 5
11 4110000129039 O形圈1AP-32.0 24311-000320 O-ring Y 1
12 4110000129033 螺栓M8X16 26106-080162 Screw Y 3
13 4110000129033 螺栓M8X16 26106-080162 Screw Y 4
14 4110000129278 螺栓M8X30 26106-080302 Screw Y 1
15 4110000129125 螺栓M8X55 26106-080552 Screw Y 2
16 4110000678044 螺栓M8X85 26106-080852 Screw Y 3
17 4110000129087 螺母26306-080002 Nut Y 3
18 4110002578021 盖板121023-01551 Pump cover Y 1
19 4110002578022 O型圈24341-000240 O-ring Y 1
20 4110000129275 螺栓M6X16 26106-060162 Screw Y 2
