E635F 2601001061 发动机总成 Engine system

1 4015000256 垫圈GB96.1-8EpZn-300HV Washer Y 5

2 4013000033 螺母GB6170-M8EpZn-8 Nut Y 6

3 26010011441 板 Plate Y 1

4 4011001214 螺栓GB16674.1-M10*50flZnyc-10.9-480 Screw Y 2

5 4110002635 排气管夹 Exhaust pipe clamp Y 1

6 4013000005 螺母GB6170-M10EpZn-10 Nut Y 2

7 26010012091 隔热垫 Heat insulation Y 1

8 4110002648 T型抱箍φ207 Clamp Y 2

9 4110002636 空滤器G068663 Air cleaner Y 1

10 26010010681 空滤支架 Bracket Y 1

11 4011000106 螺栓GB5783-M8*25EpZn-8.8 Bolt Y 2

12 4017000014 喉箍JB8870-d80 Clamp Y 3

13 26010010671 进气胶管 Hose Y 1

14 26010010661 空滤进气胶管 Hose Y 1

15 4110002578 发动机4TNV88-BSLG Engine Y 1

16 4011000447 螺栓GB16674-M10*20EpZn-8.8 Bolt Y 5

17 26010009571 管夹 Clamp Y 1

18 4110002592 消音器 Muffler Y 1

19 26010010701 消音器支架 Bracket Y 1

20 4015000162 垫圈GB97.1-10EpZn-300HV Washer Y 19

21 4011000082 螺栓GB5783-M10*25EpZn-8.8 Bolt Y 9

22 26010010711 支架 Bracket Y 1

23 4011000084 螺栓GB5783-M10*30EpZn-8.8 Bolt Y 2

24 4011001205 螺栓GB5783-M12*35flZnyc-10.9-480 Screw Y 8

25 4015000168 垫圈GB97.1-12EpZn-300HV Washer Y 8

26 4015000072 垫圈GB97.1-8EpZn-300HV Washer Y 12

27 4011001097 螺栓GB5783-M8*16EpZn-10.9 Screw Y 8

28 4011000107 螺栓GB5783-M8*30EpZn-8.8 Bolt Y 1

29 4110002593 联轴器SAE16/32 Z=15 Coupling piece Y 1

30 4110002591 减震器17-1609-45 Absorber Y 4

31 4011001207 螺栓GB5783-M16*50flZnyc-10.9-480 Screw N 4

32 4015000181 垫圈GB97.1-16EpZn-300HV Washer Y 4

33 4011000993 螺栓GB5783-M10*25EpZn-10.9 Bolt Y 8

34 26010010621 发动机右前支架 Engine mounting Y 1

35 26010010631 发动机左前支架 Engine mounting Y 1

36 4017000007 喉箍JB8870-d60 Clamp Y 8

37 26010010651 油门支架 Bracket Y 1

38 26010010691 飞轮壳端盖 Cover Y 1

39 26010011431 排气尾管 Exhaust pipe Y 1

40 26010010761 U形螺栓 U-bolt Y 1

41 26010012101 排气尾管隔热垫 Heat insulation Y 1

42 4011000481 螺栓GB16674-M8*30EpZn-8.8 Bolt Y 2

43 4110001074 安装抱箍P778810 Clamp Y 1

44 4110002641 电子式压差报警器X770774 Alarm device Y 1

45 26010010931 进气钢管 Air inlet pipe Y 1

46 4011000461 螺栓GB16674-M8*16EpZn-8.8 Bolt Y 3

47 4041002370 底板LGB160-5062 Bracket Y 1

48 4041002407 管夹LGB169-A15*12.5 Clamp Y 1

49 26020006621 橡胶套 Rubber sleeve Y 1

50 4015000207 垫圈GB97.1-6EpZn-300HV Washer Y 1

51 4011000291 螺栓GB5783-M6*30EpZn-8.8 Screw Y 1

52 4013000028 螺母GB6170-M6EpZn-8 Nut Y 1
