LG933L P4301-2943000323 驾驶室外置电气总成 Electric equipment

1 4130001685 工作灯148*86-H3-24V Lamp Y 2

2 4011000461 螺栓GB16674-M8*16EpZn-8.8 Bolt Y 1

3 29370022731 插件支架 Bracket Y 1

4 4190001839 扎丝LG13-ZS4*160 Cable tie Y 20

5 4130000290 转向开关JK802A Rocker switch Y 1

6 29370026251 支撑板 Support plate Y 1

7 4014000026 螺钉GB818-M6*16EpZn-4.8 Screw Y 2

8 4015000207 垫圈GB97.1-6EpZn-300HV Washer Y 2

9 29370026241 固定座 Retainer Y 1

10 29370026231 管夹 Clamp Y 1

11 4011000161 螺栓GB16674-M8*35EpZn-8.8 Bolt Y 2

12 4130001714 仪表盘ZL2-256C Display panel Y 1

13 4130001342 电锁JK433B Starter switch Y 1

14 4130000869 中间继电器024-1Z6GD2 Relay Y 3

15 4130000587 蜂鸣器SFM-27 Buzzer N 1

16 4014000066 螺钉GB845-ST4*10-C-H Screw Y 2

17 4130000022 闪光器SG252 Flasher unit Y 1

18 4130000912 蓄电池继电器024-1H2T-80A Relay Y 2

19 4015000110 垫圈GB97.1-5EpZn-300HV Washer Y 2

20 4014000048 螺钉GB818-M5*12EpZn-4.8 Screw Y 2

21 29430002331 仪表台线束 Cable harness Y 1

22 4130000498 侧边单框架JK931-01CKJ Switch panel Y 2

23 4130000514 暖风机开关JK931-01NFJ Rocker switch Y 1

24 4130000496 盖板JK931-01GB Cover plate Y 3

25 4130000491 后照灯开关JK931-01HZD Rocker switch N 1

26 4130000490 前照灯开关JK931-01QZD Rocker switch Y 1

27 4130000492 警示灯开关JK931-01JSD Rocker switch Y 1

28 4130000489 背光灯开关JK931-01BGD Rocker switch Y 1

29 4130000497 中间单框架JK931-01ZKJ Switch panel Y 8

30 4130000555 前大灯开关JK931-01QDD Rocker switch Y 1

31 4130001052 静音开关JK931-01JY Rocker switch Y 1
