LG956L A0394-4110002851 散热器总成(320204) Radiator assembly

1 4110001383001 液压油散热器S9110087A Hydraulic oil cooler Y 1
2 4110002851001 水散热器S9112271B Radiator Y 1
3 4110001381202 导风罩DB0016 Fan shroud Y 1
4 4110002851002 左框架KB0377 Framework N 1
5 4110002851003 传动油散热器 Oil cooler Y 1
6 4110002851004 下钢架 Framework Y 1
7 4011001296 螺栓GB16674.1-M820flZnyc-8.8-480 Screw Y 60

8 4011000723 螺栓GB5783-M820-8.8 Bolt Y 12
9 4015000036 垫圈GB93-8-65Mn Spring washer Y 12
10 4015000315 P-垫圈GB97.1-8-300HV Washer Y 16
11 4011001273 螺栓GB5783-M6*20flZnyc-8.8-480 Screw Y 8
12 4015000230 P-垫圈GB97.1-6-300HV Washer N 8
13 4015000035 垫圈GB93-6-65Mn Spring washer Y 8
14 4110002025012 蒸汽管∮8 L=1000mm 8010081000 Rubber pipe Y 1
15 4110002025013 蒸汽管∮8 L=800mm 8010080800 Rubber pipe Y 1
16 4110002851005 卡箍 Clamp N 2
17 4110002506026 临工标牌700004 Name plate N 1
18 4110002851006 上钢架KB0378 Framework N 1
19 4110002851007 右框架KB0379 Framework N 1
20 4110002025008 护网部件HB0047 Hood Y 2
21 4110002851008 硬橡胶减震垫 Damper mat N 4
22 4110002851009 下挡风板330441 Wind deflector Y 1
23 4110002851010 U型密封条8290011200 Lip seal N 1
24 4110002851011 挡风板330440 Wind deflector Y 1
25 4110002851012 U型密封条8290012890 Lip seal N 1
26 4110002851013 U型密封条8290010255 Lip seal N 2
