B876F P4100-2637000965 电气系统 Electric system

1 26370002451 红电瓶线护套 Cable sleeve Y 5

2 26370006611 电瓶线P70*1500 Battery cable Y 1

3 4011000447 螺栓GB16674-M10*20EpZn-8.8 Bolt Y 7

4 4045000164 电瓶线LGB340-70*1250P1L10L10-1L1 Battery cable Y 1

5 26370002441 黑电瓶线护套 Cable sleeve Y 4

6 26370007511 电瓶线A60*170 Battery cable Y 1

7 4130000427 电源开关K01K18-A Battery switch Y 1

8 4130000057 蓄电池6-QW-120B Wet battery N 1

9 4190001095 扎丝N90666101 Cable tie Y 5

10 26370009695 车架线束 Wiring harness N 1

11 4011000488 螺栓GB16674-M10*16EpZn-8.8 Bolt Y 7

12 4011000807 螺栓GB16674-M8*12EpZn-8.8 Bolt Y 2

13 4130000824 电喇叭3AM002952-521 Horn Y 1

14 4011000458 螺栓GB16674-M8*20EpZn-8.8 Bolt Y 6

15 14400342 扎带 Strip clamp Y 8

16 4045000078 电瓶线LGB340-25*450A1L8L10-1L1 Battery cable Y 2

17 4015000110 垫圈GB97.1-5EpZn-300HV Washer Y 4

18 4014000048 螺钉GB818-M5*12EpZn-4.8 Screw Y 2

19 4130002657 接触器JCC200/1C 12·48 Relay Y 1

20 4130001296 机油压力开关YK208B1 Pressure switch Y 1

21 26370009581 预热继电器固定架 Bracket Y 1

22 4045000079 电瓶线LGB340-25*600A1L8L10-1L1 Battery cable Y 1

23 26370009351 预热保险固定板 Plate Y 1

24 4045000038 电瓶线LG340-50*500P1L10L12-4 Battery cable Y 1

25 4130000202 温度传感器WDG1371 Temperature sensor Y 1

26 4011000137 螺栓GB16674-M12*20EpZn-8.8 Bolt Y 1

27 4130001480 保险丝座ANM-C Fuse box Y 1

28 4130001468 保险丝ANM 225 Fuse Y 1

29 4011000194 螺钉GB818-M6*12EpZn-4.8 Screw Y 3

30 4015000207 垫圈GB97.1-6EpZn-300HV Washer Y 9

31 4190000020 扎丝LG13-ZS4*250 Cable tie Y 73

32 26370008501 蓄电池固定支架 Bracket Y 1

33 11210605 支架 Bracket Y 1

34 11210604 支架 Bracket Y 1

35 4130001612 压力开关YK-ZF Pressure switch Y 1

36 4011001008 螺栓GB5782-M10*250EpZn-8.8 Screw Y 2

37 4015000162 垫圈GB97.1-10EpZn-300HV Washer Y 2

38 4015000025 垫圈GB93-10-65Mn Spring washer Y 2

39 4011001297 螺栓GB16674.1-M8*16flZnyc-8.8-480 Screw Y 4

40 26290023101 左后灯支架 Lantern bracket Y 1

41 26370009711 后尾灯过渡线 Wiring harness Y 2

42 4130002960 后尾灯-12V Tail light N 2

43 4014000524 螺钉GB818-M6*16flZnyc-8.8-480 Screw Y 4

44 4045000108 电瓶线LGB340-50*200P1L10L10-4 Battery cable Y 1

45 4014000088 螺钉GB818-M5*16EpZn-4.8 Screw Y 6

46 26290023131 右后灯支架 Lantern bracket Y 1

47 4130002841 延时继电器0501327299 Relay Y 1

48 4130000749 点烟器8EZ008022-001 Cigarette lighter Y 1

49 26370006933 组合仪表盘SDLG-10-OIL TEP Display panel Y 1

50 11217633 启动开关 Starter switch Y 1

51 4014000026 螺钉GB818-M6*16EpZn-4.8 Screw Y 6

52 4130002644 中央电器控制盒L1-12F17R12-06 Fuse and relay unit Y 1

53 4130002127 前左组合灯-12-1500 Lamp Y 1

54 4130000961 接触器JCC100/1C12·24 Relay Y 2

55 4014000021 螺钉GB818-M4*12EpZn-4.8 Screw Y 4

56 4015000135 垫圈GB97.1-4EpZn-300HV Washer Y 4

57 26370009631 接插件固定架 Bracket Y 1

58 4011000461 螺栓GB16674-M8*16EpZn-8.8 Bolt Y 2

59 4130000870 中间继电器012-1Z6GD2 Relay Y 2

60 4130002187 转向指示灯-12V Indicator lamp Y 2

61 4130002189 远光指示灯-12V Indicator lamp Y 1

62 4130002188 手刹指示灯-12V Indicator lamp Y 1

63 4120004340 制动尾灯压力开关 Switch Y 1

64 26370009705 仪表台线束 Wiring harness N 1

65 29330031081 橡胶套D50 Rubber sleeve Y 1

66 11223068 脚控开关 Foot operated switch Y 1

67 4130000290 转向开关JK802A Rocker switch Y 1

68 4190001832 扎丝RTGB-200ST Cable tie Y 5

69 4130002128 前右组合灯-12-1500 Lamp Y 1

70 4130001722 温度传感器WDG1371D1 Temperature sensor Y 1

71 4130000498 侧边单框架JK931-01CKJ Switch panel Y 8

72 4130000555 前大灯开关JK931-01QDD Rocker switch Y 1

73 4130000497 中间单框架JK931-01ZKJ Switch panel Y 4

74 4130000490 前照灯开关JK931-01QZD Rocker switch Y 1

75 4130000492 警示灯开关JK931-01JSD Rocker switch Y 1

76 4130002935 驱动模式开关JK931-01QDMS Rocker switch N 1

77 4130000493 刮雨器开关JK931-01GYQ Rocker switch N 1

78 4130000491 后照灯开关JK931-01HZD Rocker switch N 1

79 4130000496 盖板JK931-01GB Cover plate Y 5

80 4130001835 前后喷水开关JK931-01PS Rocker switch Y 1

81 4043003027 密封护套LGB346-3*30*28 Rubber sleeve Y 2

82 4015000369 垫圈GB96.1-22EpZn-300HV Washer gb96.1-22epzn-300hv Y 1
