WD10G220E23（DHD10G0618） A01167-4110003316 Parts box group

1 4110001755047 六角螺塞90003962025 Plug Y 9
2 4110002872008 六角法兰面承面带齿螺栓90011430071 Screw Y 8
3 4110001755052 油门软轴支架612600013464 Bracket Y 1
4 4110000924025 复合密封垫圈612600080688 Washer Y 2
5 4110000924118 六角法兰面承面带齿螺母612600061720 Nut Y 6
6 4110000556131 密封垫圈612600080201 Sealing ring Y 1
7 4110000556130 密封垫圈612600080200 Sealing ring Y 19
8 4110000924048 空心螺栓90003962621 Eye bolt Y 4
9 4110003450005 六角头螺栓全螺纹90011270005 Screw Y 4
10 4110001654067 2型全金属六角紧锁螺母90003888470 Nut Y 4
11 4110000556227 增压器垫片61564G-1110068 Gasket Y 1
12 4110000924137 平垫圈90003930271 Washer Y 8
13 4110003450007 燃油进油管总成612600083693 Hose assembly Y 1
14 4110000557016 双头螺柱612600110282 Stud Y 4
15 4110000113017 垫片615T1110071 Washer Y 1
16 4110001592030 软管卡箍 90003989301 Clamp Y 2
17 4110000924173 软管卡箍90003989320 Clamp Y 1
18 4110001014006 软管卡箍90003989318 Clamp Y 1
19 4110000924145 1型六角螺母90003871305 Nut Y 4
20 4110000924080 弹簧垫圈90003931122 Spring washer Y 4
21 4110000924024 燃油管总成612600080593 Fuel pipe Y 1
22 4110000556229 油路连接胶管612600112716 Hose Y 1
23 4110000924022 油管612600080071 Fuel pipe Y 1
