L989F A0100-2901007515 Engine　assemble

1 4017000024 环箍QC390-D26 Clamp Y 4

2 4090000176 胶管HG2491-16*2900 Hose Y 1

3 4090000194 胶管HG2491-16*2000 Hose Y 1

4 11222791 发动机SD130A Engine Y 1

5 29010075181 油浴式空滤模块 Oil filter assy N 1

6 29010075201 进排气系统 Air system N 1

7 29010039041 发动机电器系统附件 Electric equipment N 1

8 29010046221 多楔带10PK1500 Belt Y 1

9 29010076741 供油系统 Fuel filter N 1

10 4015000433 垫圈GB97.1-10flZnyc-300HV-480 Washer Y 2

11 4011001347 螺栓GB5782-M10*60flZnyc-8.8-480 Bolt Y 2

12 29010035101 支架 Bracket Y 1

13 4011000601 螺栓GB16674-M10*120EpZn-8.8 Bolt Y 2

14 4011001270 螺栓GB5783-M10*35flZnyc-8.8-480 Screw Y 2

15 4013000370 螺母GB6170-M10flZnyc-8-480 Nut Y 14

16 4013000395 螺母GB889.1-M16flZnyc-8-480 Nut Y 4

17 4015000436 垫圈GB97.1-16flZnyc-300HV-480 Washer Y 4

18 4011001346 螺栓GB5782-M16*80flZnyc-10.9-480 Bolt Y 4

19 29010023391 双头螺柱 Stud Y 12

20 4015000025 垫圈GB93-10-65Mn Spring washer Y 12

21 4110001774 发动机前置减震器20503551 Absorber Y 1

22 4011001349 螺栓GB5783-M14*50flZnyc-8.8-480 Bolt Y 2

23 4015000435 垫圈GB97.1-14flZnyc-300HV-480 Washer Y 2

24 4011001251 螺栓GB5783-M12*45flZnyc-8.8-480 Screw Y 4

25 29010030871 防松套 Adjusting washer Y 4

26 29010031031 梁 Square bar N 1

27 4120000067 暖风机水阀LG12-NFJSF Valve Y 2

28 29010030601 暖风接头 Nipple Y 2

29 29010030621 O型圈 O-ring Y 2

30 4011001297 螺栓GB16674.1-M8*16flZnyc-8.8-480 Screw Y 2
