L978F 发动机电气总成 Engine electric system P4400-2944000151

1 14400342 扎带 Strip clamp Y 6

2 4011001294 螺栓GB16674.1-M10*20flZnyc-8.8-480 Screw Y 8

3 4011001297 螺栓GB16674.1-M8*16flZnyc-8.8-480 Screw Y 9

4 26370001172 支架 Bracket Y 2

5 26370002451 红电瓶线护套 Cable sleeve Y 1

6 29370018861 支板 Bracket Y 1

7 4190001095 扎丝N90666101 Cable tie Y 4

8 26370001072 支架 Bracket Y 2

9 29440001522 ECU线束 Wiring harness Y 1

10 29440000111 接地线P50*500 Battery cable Y 1

11 4011001302 螺栓GB16674.1-M10*16flZnyc-8.8-480 Screw Y 1

12 26370002441 黑电瓶线护套 Cable sleeve Y 2

13 29370027801 电瓶线A25*350 Battery cable Y 1

14 4014000512 螺钉GB818-M6*12flZnyc-4.8-480 Screw Y 2

15 4015000424 垫圈GB97.1-6flZnyc-300HV-480 Washer Y 9

16 4130001480 保险丝座ANM-C Fuse box Y 1

17 4130001464 保险丝ANM 125 Fuse Y 1

18 29440000181 电瓶线A15*120 Battery cable Y 1

19 26370002431 红电瓶线护套 Cable sleeve Y 2

20 4130001988 接触器JCC200/1C24·48A Relay Y 1

21 4014000515 螺钉GB818-M5*10flZnyc-4.8-480 Screw Y 2

22 4015000431 垫圈GB97.1-5flZnyc-300HV-480 Washer Y 2

23 28440000131 电瓶线P25*3500 Battery cable Y 1

24 29440000161 过渡板 Plate Y 1

25 4011001285 螺栓GB5783-M6*16flZnyc-8.8-480 Screw Y 3

26 4130001081 电子油门踏板WL400244 Accelerator pedal Y 1

27 4011001276 螺栓GB16674.1-M6*20flZnyc-8.8-480 Screw Y 4

28 4013000372 螺母GB6170-M6flZnyc-8-480 Nut Y 4

29 4130002655 多态开关3735075-BD01 Switch Y 1
