L959F 尾气处理系统 Assembly compound A0170-2901007562

1 4011001327 螺栓GB5782-M12*60flZnyc-10.9-480 Screw Y 8

2 4015000428 垫圈GB97.1-12flZnyc-300HV-480 Washer Y 8

3 29030026851 隔套 Spacer sleeve Y 8

4 11220418 传感器单元 Sensor Y 1

5 11220419 传感器单元 Sensor Y 1

6 11220420 传感器单元 Sensor Y 1

7 29010052371 管夹 Clamp Y 1

8 29010075811 排气管 Exhaust pipe Y 1

9 4110001754 排气尾管 Pipe Y 1

10 4011001248 螺栓GB5783-M10*25flZnyc-8.8-480 Screw Y 7

11 4015000426 垫圈GB96.1-10flZnyc-300HV-480 Washer Y 8

12 29010075791 氮氧传感器支架 Bracket Y 1

13 29010075651 SCR安装板 Bracket Y 1

14 4011001403 螺栓GB16674.1-M8*25flZnyc-10.9-480 Bolt N 17

15 29010048111 安装板 Plate N 1

16 11220422 V型抱箍 V-band clamp Y 3

17 11220423 衬垫 Gasket Y 3

18 11220424 排气钢管 Exhaust pipe Y 1

19 11220425 排气软管 Exhaust hose Y 1

20 11223950 排气管 Exhaust pipe Y 1

21 11223951 半截夹 Half clamp Y 1

22 11223952 半截夹 Half clamp Y 1

23 11223953 导线 Wire Y 1

24 11223954 支架 Bracket Y 1

25 4011001275 螺栓GB16674.1-M6*16flZnyc-8.8-480 Screw Y 2

26 4011001301 螺栓GB16674.1-M8*30flZnyc-8.8-480 Screw Y 4

27 29010049401 走线板 Plate Y 1

28 4015000425 垫圈GB96.1-8flZnyc-300HV-480 Washer Y 25

29 4011001246 螺栓GB5783-M8*16flZnyc-8.8-480 Screw Y 5

30 4015000433 垫圈GB97.1-10flZnyc-300HV-480 Washer Y 4

31 29010047611 防护板 Plate Y 1

32 4011001404 螺栓GB5783-M10*25flZnyc-10.9-480 Bolt Y 5

33 4013000005 螺母GB6170-M10EpZn-10 Nut Y 2

34 29010075661 右支撑 Bracket Y 1

35 29010075671 左支撑 Bracket Y 1

36 29010047641 SCR支架板 Bracket Y 1

37 29010047691 隔套 Spacer bushing Y 2

38 4011001405 螺栓GB5783-M8*40flZnyc-8.8-480 Screw Y 6

39 4011001406 螺栓GB5783-M8*50flZnyc-8.8-480 Screw Y 2

40 29010047671 方管 Square tube Y 2

41 29010047681 走线板 Bracket Y 1

42 29010047661 隔板 Bracket Y 1

43 4011001396 螺栓GB5783-M8*35flZnyc-8.8-480 Screw Y 2

44 29010047651 DPF支架板 Bracket Y 1

45 4011001247 螺栓GB5783-M8*20flZnyc-8.8-480 Screw Y 4

46 4013000373 螺母GB6170-M8flZnyc-8-480 Nut Y 12
