发动机总成WD10G220E23 Cylinder block preassembly A01103-4110003316

1 4110000924058 铆钉612600013437 Rivet Y 2
2 4110001592005 碗形塞 90003982121 Plug Y 4
3 4110001755025 气缸体612600013705 Cylinder block N 1
4 4110001592008 碗形塞 90003989289 Plug Y 4
5 4110000924056 碗形塞90003989215 Plug Y 3
6 4110000556251 主轴承螺栓614010217 Screw Y 4
7 4110000556250 主轴承螺栓614010114 Screw Y 10
8 4110001755026 曲轴箱612600013749 Crankcase N 1
9 4110001755063 圆柱销90003901604A Pin Y 3
10 4110001592011 凸轮轴衬套 612600010990 Bushing Y 1
11 4110001015067 碗形塞90003989204 Plug Y 1
12 4110000924036 凸轮轴衬套61560010029 Camshaft bushing Y 6
13 2010900111027 碗形塞90003989210 Plug Y 6
