L959F Engine system A0100-2901004663

1 29010054801 暖风水管 Hose Y 1

2 4017000024 环箍QC390-D26 Clamp Y 4

3 29010054811 暖风水管 Hose Y 1

4 4011001297 螺栓GB16674.1-M8*16flZnyc-8.8-480 Screw Y 5

5 26370001941 管夹 Clamp N 3

6 11220200 发动机 Engine Y 1

7 29010047351 进气系统 Assembly compound N 1

8 29010047361 尾气处理系统 Assembly compound N 1

9 29010047371 DEF系统 Assembly compound N 1

10 29010047381 发动机安装系统 Assembly compound N 1

11 4120000067 暖风机水阀LG12-NFJSF Valve Y 2

12 29010047391 燃油供给系统 Assembly compound N 1

13 29010047401 过渡接头 Nipple Y 1

14 4015000196 垫圈JB1002-26-T2 Washer Y 1

15 29010047551 通气管 Hose Y 1

16 26370001951 管夹 Clamp Y 1

17 29010047561 支架 Bracket Y 1

18 4011001314 螺栓GB5783-M8*12flZnyc-8.8-480 Screw Y 3

19 4015000433 垫圈GB97.1-10flZnyc-300HV-480 Washer Y 8

20 29010023401 双头螺柱 Stud Y 8

21 4013000370 螺母GB6170-M10flZnyc-8-480 Nut Y 8

22 4015000425 垫圈GB96.1-8flZnyc-300HV-480 Washer Y 3

23 4041000867 管夹LGB167-1060 Clamp Y 2

24 4017000011 喉箍JB8870-d32 Clamp Y 1
