L948F 发动机电气系统 Engine electric system P4400-2944000060

1 4011001276 螺栓GB16674.1-M6*20flZnyc-8.8-480 Screw Y 9

2 4015000424 垫圈GB97.1-6flZnyc-300HV-480 Washer Y 6

3 4011001389 螺栓GB5783-M6*25flZnyc-8.8-480 Screw Y 2

4 4011001277 螺栓GB16674.1-M8*35flZnyc-8.8-480 Screw Y 7

5 4011001297 螺栓GB16674.1-M8*16flZnyc-8.8-480 Screw Y 40

6 11214766 管夹 Clamp N 3

7 14400341 扎带 Strip clamp Y 3

8 14400340 扎带座 Strip clamp Y 3

9 14400342 扎带 Strip clamp Y 25

10 4011001294 螺栓GB16674.1-M10*20flZnyc-8.8-480 Screw Y 2

11 26370001072 支架 Bracket Y 2

12 29440000612 发动机线束 Cable harness Y 1

13 29370026641 电瓶线A20*200 Battery cable Y 1

14 29370027031 UL电瓶线A20*2200 Battery cable Y 1

15 11219739 传感器 Sensor Y 1

16 4011001343 螺栓GB16674.1-M6*12flZnyc-8.8-480 Screw Y 1

17 29440000071 电瓶线P15*200 Battery cable Y 1

18 29370021261 接地线P15*350 Ground cable Y 1

19 4011001275 螺栓GB16674.1-M6*16flZnyc-8.8-480 Screw Y 4

20 4130002003 HMIM11383485 Connector Y 1

21 4014000512 螺钉GB818-M6*12flZnyc-4.8-480 Screw Y 4

22 4130002013 电子油门踏板WL402067 Accelerator pedal Y 1

23 29370023201 接地线P50*500 Ground cable Y 1

24 4013000372 螺母GB6170-M6flZnyc-8-480 Nut Y 1

25 4013000373 螺母GB6170-M8flZnyc-8-480 Nut Y 3

26 4013000370 螺母GB6170-M10flZnyc-8-480 Nut Y 1

27 4015000430 垫圈GB97.1-8flZnyc-300HV-480 Washer Y 2

28 4011001425 螺栓GB16674.1-M8*40flZnyc-8.8-480 Bolt Y 1

29 26370002431 红电瓶线护套 Cable sleeve Y 1
