L956FH 散热器总成(320204) Radiator assembly A0394-4110003617

1 4110002286009 传动油散S9111381C Oil cooler N 1

2 4110002286001 水散热器S9110798B Radiator Y 1

3 4110002025002 液压油散热器S9110745A Radiator Y 1

4 4110003617001 框架总成KZ9113270 Radiator bracket N 1

5 4110003232002 挡风板330540 Wind deflector N 1

6 4110003232003 U型密封条8290013050 Sealing strip N 1

7 4110003617002 导风罩DB0576 Fan shroud Y 1

8 4110003617003 防护网HB0285 Fan guard Y 2

9 4110003617004 减震垫720061 Damper mat N 2

10 4110003617005 法兰面螺栓610402 Screw N 2

11 4110002025019 不锈钢大垫片631530 ∮12不锈钢 Washer N 2

12 4110002975215 六角头螺栓610202 Screw N 22

13 4110002943004 弹垫632300 Spring washer N 28

14 4110001688022 平垫630330 Plain washer N 56

15 4110002945016 六角螺母621200 Nut N 28

16 4110001665011 法兰面螺栓614211 Screw N 14

17 4110003075023 锁扣弹性环330532 Clamp N 2

18 4110003075022 锁扣定销330531 Pin N 2

19 4110003075021 锁扣安装轴330530 Shaft N 2

20 4110003075020 锁扣橡胶垫720044 Rubber mat N 2

21 4110003075019 六角螺母621400 Nut N 2

22 4110003075014 六角头螺栓610205 Screw N 6

23 4110003617006 螺栓614302 Screw N 4

24 4110003617007 旋转框架KB0498 Framework N 1

25 4110001929 Ⅱ型90Kpa复式加水口盖FG2 Cap Y 1

26 4110002233206 放水阀739001 Drain valve Y 1

27 4110002506023 放水管8000080800 Hose Y 1

28 4110002286007 卡箍990002 Clamp N 1
