L946 Control housing assembly L3200-2932000994

1 29320010191 扶手总成 Hand rail Y 1
2 29320009851 扶手 Arm rest Y 1
3 4015000207 垫圈GB97.1-6EpZn-300HV Washer Y 2
4 4011000423 螺栓GB5783-M612EpZn-8.8 Screw Y 2 5 29320010202 扶手支架 Bracket Y 1 6 4015000198 垫圈GB96.1-6EpZn-300HV Washer Y 7 7 4014000040 螺钉GB818-M620EpZn-4.8 Screw Y 3
8 29320010041 上盖 Cover Y 1
9 4011000105 螺栓GB5783-M820EpZn-8.8 Bolt Y 5 10 4015000256 垫圈GB96.1-8EpZn-300HV Washer Y 5 11 29320010451 操纵箱焊接总成 Control housing Y 1 12 29320010581 外侧板 Plate Y 1 13 29320010021 顶板总成 Plate Y 1 14 4011000289 螺栓GB5783-M616EpZn-8.8 Bolt Y 4
15 4015000207 垫圈GB97.1-6EpZn-300HV Washer Y 8
16 4019000080 手柄JB7270.12-M1080 Control handle Y 1 17 29320009921 锁紧套 Lock washer Y 1 18 4015000197 垫圈GB96.1-10EpZn-300HV Washer Y 1 19 29320010151 海绵 Sponge Y 1 20 29320010141 海绵 Sponge Y 2 21 4011000481 螺栓GB16674-M830EpZn-8.8 Bolt Y 2
22 4015000072 垫圈GB97.1-8EpZn-300HV Washer Y 10
23 4011001280 螺栓GB5783-M1040flZnyc-8.8-480 Screw Y 4 24 4043002603 防松套LGB331-102016flZnyc-45 Attaching sleeve Y 4 25 29320010591 管夹 Plate Y 1 26 26240004831 橡胶套 Rubber sleeve Y 1 27 29320010301 限位块 Block Y 1 28 4011000106 螺栓GB5783-M825EpZn-8.8 Bolt Y 1
