L946 变矩器(370804) Torque converter B0410-4110002524

1 4011001094 螺栓GB21-M10*25-10.9 Screw Y 9

2 4015000381 垫圈GB7244-10-65Mn Washer N 9

3 4110000011081 导轮座YB315Z5-13A Seat Y 1

4 4110000011082 密封环YB315Z5-33 Sealing ring Y 1

5 4110000011083 密封环YB315Z5-12A Sealing ring Y 1

6 7200000846 铆钉3*6 04418-03060 Rivet Y 4

7 4110000841001 铭牌YJSW315-6G-BP Name plate N 1

8 4110002525003 螺栓01010-80816 M8*16 Screw Y 12

9 4110000084130 垫圈8 01602-20825 Washer Y 50

10 4110000011088 垫板YB315Z5-06D Spacer Y 1

11 4110000011089 胶垫YB315Z5-07D Gasket Y 1

12 4110002524001 壳体YB315Z5-08D-04 Housing Y 1

13 4110000011118 衬垫YB315Z5-05 Gasket Y 1

14 4110000483001 齿轮YJSW315-8A-00004 Gear Y 1

15 4021000076 滚动轴承GB276-6017 Ball bearing Y 2

16 4011000776 螺栓GB5782-M8*35-8.8 Screw Y 38

17 4110000011092 泵轮YJSW315-6C-00002 Impeller Y 1

18 4013000162 螺母GB6170-M8-8 Nut Y 24

19 4110000011094 压紧垫片YB315Z5-22A Washer Y 1

20 4110000011095 导轮YJSW315-6C-00001 Stator Y 1

21 4015000208 挡圈GB894.1-85-65Mn Retaining ring Y 1

22 4110000011096 调整垫YB315Z5-30/31/32 Washer Y 1

23 4110000194010 Ⅱ涡轮毂YB315Z5.1-2A-2 Hub N 1

24 4110000194011 Ⅱ涡轮YJSW315-6C-11001 Turbine N 1

25 4110002524002 垫片YB315Z5.1-2A-3 Washer N 1

26 4110002524003 铆钉04400-00824 Rivet N 16

27 4110000160078 Ⅰ涡轮YJSW315-2A-10001 Turbine N 1

28 4021000110 滚动轴承GB276-6013 Ball bearing Y 1

29 4110000359052 接头1YB315Z5-10L Nipple Y 1

30 4110000011098 管接头YB315Z5-14S Nipple Y 2

31 4110000011104 螺塞YB315Z5-15L① Plug Y 1

32 4110000011128 垫圈30 YB315Z5-09组合密封垫圈 Washer N 3

33 4110000011100 阀盖YB315Z5-17A Bracket Y 1

34 4110000011107 调压垫YB315Z5-28.29 Washer Y 1

35 4110000011101 弹簧YB315Z5-18A Spring Y 1

36 4110000011102 调压垫YB315Z5-16.21 Washer Y 1

37 4110000011103 阀杆YB315Z5-26A Valve rod Y 2

38 4110000011105 压板YB315Z5-19A Anchor plate Y 1

39 4110000011106 弹簧YB315Z5-20 Spring Y 1

40 4110000011129 管接头YB315Z5-24K Nipple Y 1

41 4110000518010 涡轮毂YJSW315-6C-12001 Turbo housing kit N 1

42 4110000160079 涡轮罩YJSW315-6C-12002 Cover N 1

43 4110000011134 销YB315Z5.1-4A Pin N 9

44 4021000018 滚动轴承GB276-6210 Ball bearing Y 1

45 4110000194001 罩轮YJSW315-2A-00002 Cover Y 1

46 4110000160056 中节1YJSW315-2A-00001 Flange Y 1

47 4110000194006 螺母M12-01580-11210 Nut Y 12

48 4110000160054 垫圈01602-21236 Gasket Y 24

49 4011000212 螺栓GB5782-M12*70EpZn-8.8 Screw Y 12

50 4110000194008 盖板YJSW315-2A-00004 Cover plate Y 1

51 4110000194009 垫YJSW315-2A-00005 Sealing ring Y 1

52 4110000160059 过渡轴1YJSW315-2A-20000 Shaft Y 1

53 4011000498 螺栓GB5782-M12*45EpZn-8.8 Screw Y 6

54 4110002524004 调整垫YB315Z5-34-1.2.3.4.5 Shim N 1

55 4110000011114 弹性板总成YJSW315-20000 Plate Y 1

56 4110000011115 弹性板YJSW315-20001 Plate Y 1

57 4110000011116 圆垫板YB315Z5-04 Shim Y 1

58 4011000770 螺栓GB5782-M12*30EpZn-8.8 Screw Y 6
